DONGFENG 4X2 6.5CBM Stainless Steel Water Truck

US$ 20,000 - 39,000 MOQ: 1 Set

Key Specifications

Drive Wheel:

4x2

Fuel:

Diesel

Transmission Type:

Manual

Hubei Jiangnan Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Drive Wheel 4x2

Fuel Diesel

Transmission Type Manual

Condition New

Sprinkling Area (m) 12 - 16m

Emission Standard Euro 4

Engine Capacity 4 - 6L

Tank Volume 5001 - 10000L

Dimensions (L x W x H) (mm) 7100*2400*2760

Brand Name JDF

Place of Origin Hubei, China

Model Number JDF5120GSSDFL

Gross Vehicle Weight 12490

Certification CCC ISO

Warranty 1

After-sales Service Provided Overseas service center available

DONGFENG 6.5m³ Water Tank TRUCK

Basic Information
Vehicle name	Water TRUCK		Chassis:			DFL1120B1
Outline size(L×W×H) (mm)	710024002760		Cargo inline size(L×W×H)(mm):			/
Rating mass(kg)	6200		Empty mass(Kg):			6095
Full mass(kg)	12490		Emission standard			Euro 4
Engine Information
Model	ISDe180 30		Type		6 Cylinder Diesel engine
Power/displacement(KW/ML)	132(179HP)/4500		Manufacture		CUMMINS
Chassis Information
Wheelbase(mm):	3800,3650		Axle load(kg)		4450/8040
Tire	9.00-20,9.00R20,10.00-20,10.00R20		Max speed (km/h)		90,110,80
Front suspension(mm)	1430		Rear suspension(mm)		1860/1320
Front track(mm)	1880		Rear track(mm)		1800,1860
Approach angel(°)	20		Departure angle(°)		22/30
Steering	Power steering		Brake		Air brake
Cabin	3
Special function
Front flush ,rear sprinkle, side spray
Tank capacity(m³)	6.5m³	Tank material		Carbon steel
Trade terms
Quote Lifetime	30workdays (we promise the quote is effective in the lifetime!)
Payment terms	1. 30% by T/T in advance, 70% by T/T against the copy of Bill-of-Lading. 2. Letter of credit payment for some countries and regions.
Deliver time	10workdays for LHD , 20workdays for RHD after receive 30% earnest money
MOQ	1set
Supply quantity	3000sets/month
Package	waxing
