1. custom fpc2. double-side flexible printed circuit
3. lcd display fpc
fpc specifications:
1. customized flex printed circuit board
2. fpc manufacture in shenzhen
3. all test
Double-side:
Applied with double sides material to make pattern on both sides then add the cover layer on each side
1. Electronic characteristics :
Circuit rating: 35V (DC), 100mA, 1W
Contact resistance: 10Ω--500Ω (According the trace length and materials to comfirm)
Insulation resistance:> 100MΩ 250V DC
Contact bounce: ≤ 5ms Dielectric withstand:250VRms (50-60Hz 1min)
Life expectancy: flat type ≥ 500 million times, tactile type: ≥ 100 million times
2. Mechanical Properties Actuation force: flat type 57-284g (2-10 Oz), tactile type 170-397g (6-14 Oz) Switch stroke: flat type 0.1-0.5mm, tactile type 0.6-1.5mm
3. Environmental parameters :
Operating Temperature: -40 - +80 , Storage temperature: -40 - +85
Humidity: 40 , 90% -95%, 240 hours
Multi-layer:
Binding a single side and a double sides FPC together or binding a double sides and a double sides FPC together.
Thick bottom material: 25, 50, 75, 100um, 1 / 2, 1, 2, 3mil
Thick copper conductor: 18, 35, 70um, 1 / 2, 1, 2oz
Material: polyester and polyimide
Copper: RA, ED
Minimum aperture: 0.2mm
Minimum spacing: 0.1mm
The smallest ring porous: 0.1mm
The largest panel size: 400 x 400mm
Plating: welding, nickel, gold
Volume Resistance aluminum: 1 x 1015 (IPC-TM-650 2.5.6.17)
Dissipation factor (1MHz): 0.04 (MIL-P55617)
Solder heat resistance: 300 degrees C/10 seconds
Strength: 5kV (IPC-TM-650 2.5.6.1)
Insulation Resistance: 1,000 mW (IPC-TM-650: 2, 6, 3, 2)
