Help Center9KW HSD Air Cooled Spindle BT30 Holder Carousel ATC Cnc Woodworking Machinery Supplier's Choice
Related Products
-
Auto Tool Changer Cnc Router in MalaysiaUS$ 15,000 - 30,000MOQ: 1 Set -
Korea Cnc Router MachineUS$ 10,000 - 20,000MOQ: 1 Set
-
Pattern Maker 1530 Cnc Router Sale in Bangladesh Supplier's ChoiceUS$ 3,000 - 8,000MOQ: 1 Set
-
3d Carving Cnc Wood Carving Budda FaceUS$ 20,000 - 30,000MOQ: 1 Set
-
SM25CK Door Hinge Making Wood Drilling MachineUS$ 3,000 - 8,000MOQ: 1 Set
cnc woodworking machinery
1.3kw water cooling spindle
2.vacuum working table
3.CE,FDA,CIQ
4.Taiwan HIWIN linear guide
Applicable industry:
wooden industry:
Sheet plane, three-dimensional wave board processing, screen, craft fan window processing,cabinet doors, solid wood door, craft door, paint-free door carving,cutting,engraving,drilling and other processing.
Other industry:
Building model,wooden model,wooden aviation model, propeller, car foam mold,violin,erhu and other instruments three-dimensional surface,shape cutting and surface pattern carved musical instrument,calligraphy plaque,carved frame.
This machine can engrave a flower-shaped carved door skin in three minutes with the speed 20m/min, if change the tool, each changing need 20s, so it can complete 150pcs door skin, 75pcs door in one day (eight hour working),
Technical Parameter:
No. |
Description |
Parameter |
1 |
X,Y working area |
1500*3000mm |
2 |
Z working area |
200mm |
3 |
Working Accuracy |
0.05mm |
4 |
Repositioning Accuracy |
0.05mm |
5 |
Frame Structure |
Welding Steel structure |
6 |
Table type |
Vacuum Table+T-Slot |
7 |
Max traveling speed |
50000mm/min |
8 |
Max working speed |
25000mm/min |
9 |
Interface |
COM32 |
10 |
Command |
G code file, *.U00, *.plt,*.mmg,*.nc |
11 |
Surroundings for software |
Windows 98/2000/XP |
12 |
Working voltage |
3PH AC380V/50HZ |
13 |
Spindle rotating speed |
0-24000rpm/min |
14 |
Drive Motor |
Japan servo motor |
15 |
Carving diameter |
3.175/4/12.7mm |
16 |
Operation system |
Taiwan LNC control system |
17 |
Spindle |
7.5 KW water cooling spindle |
18 |
Gross weight |
1800kg |
19 |
Packing Size |
330*230*190cm |
Machine parts:
Samples:
Our service:
1.We test equipment at least 3-5 days to ensure our users to receive perfect machines.
2. We guarantee that every part of machine is totally new and clean before delivery.
3. We supply 7*24 after sale service from our Service Department.
4.WE can send technical person to help customer install machine on site
5.We provide many online service such as Skype, MSN, QQ, What'sapp, Wechat, Email, and Videl call
6.We provide CD Video to show how to operate the cnc router
Package:
Jinan Sameng Machinery Manufacture Co., Ltd. Is specialized manufacturer of CNC ROUTER, metal mould machine, cnc wood engraving machine, cnc stone engraving machine, laser cutting macchine, our products are exported to England, Spain, Brazil, Turkey, America, Asia, Middle East, South Africa etc. and have a good reputation in the industry.
As CE ISO certified manufacturer, we can guarantee a competitive price and excellent quality. We treasure each chance to cooperate with you.
Exhibtions:
