Amplifier Module
H1.2D2 : 1-way amplifier module with DSP
Power: 1200W @8ohms,2400W @4ohms.
Big power switch-power supply
180V-264V Wide Operating Voltage
Intelligent Short- Circuit ,Overload Protection
High Efficiency, Low Heat , Silence Natural Cooling without Fan
Variety Of Power Watts, available for different Usage
| Model | Test Conditions | Parameter | Unit | ||
| H1.2D2 | CH1 | CH2 | CH3 | ||
| Output power | RL=8OHMS,THD<0.5%,fCH1=120Hz,fCH2=1KHz,fCH3=8KHz | 1200W | Watts | ||
| RL=4OHMS,THD<0.5%,fCH1=120Hz,fCH2=1KHz,fCH3=8KHz | 2400W | ||||
| RL=2OHMS,THD<0.5%,fCH1=120Hz,fCH2=1KHz,fCH3=8KHz | Deactivated | Deactivated | |||
| Input sensitivity | Peak input signal at output working RMS and ALC system on critical point. | 6.4 | 6.4 | 6.4 | VP-P |
| VO=VP(RMS),THD<0.5%,ALC=Deactivated | |||||
| Max input signal | Input Vp-p signal distortion | 20 | 20 | 20 | VP-P |
| VO=VP(RMS),THD<5%,ALC=Enabled | |||||
| Frequency Response | RL=4OHMS,THD<0.5%,POUT=PRMS/4 | 20~1000 | 100~8000 | 500~20000 | Hz |
| Modulating frequency | PWM operating frequency | 200(±5%) | 200(±5%) | 400(±5%) | KHz |
| Phase offset Frequency | Self-excited frequency afer shut down | 26.5 | 26.5 | 35.2 | KHz |
| phase compensation circuit,BW far away the frequency | |||||
| Delay Time Ton | Time on turn on the power till the signal on way | VER.AF13=19;VER.AF14=10 | S | ||
| Delay Time Toperateion | Time on the signal from channel on to be stable | VER.AF13=0.5;VER.AF14=1.5 | S | ||
| Delay Time TSTAR | Time on system power on to be standby power | 0.8 | S | ||
| Dead signal carrier | Dead signal carrier on Each channel | 100 | 100 | 550 | mV |
