Help CenterHydraulic Wheel and Tipping Diesel FY20 Site Dumper
US$ 5,000 - 7,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Drive Wheel:
4x2
Capacity (Load):
1 - 10t
Horsepower:
150 - 250hp
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Containerized Export Russia Market Diesel SITE DUMPERUS$ 1 - 1MOQ: 1 Unit -
Export South America Market SITE DUMPERUS$ 1 - 1MOQ: 2 Units
-
Four Drive Use Deutz Diesel Mini Site DumperUS$ 1 - 1MOQ: 1 Unit
-
2.0 Ton Site Dumper Mini DumperNegotiableMOQ: 1 Set
-
China Biggest Made Top All Site Dumper/Tipper/Tip Lorry FactoryNegotiableMOQ: 1 Set
Drive Wheel
4x2
Capacity (Load)
1 - 10t
Horsepower
150 - 250hp
Condition
New
Transmission Type
Manual
Emission Standard
Euro 2
Fuel Type
Diesel
Gross Vehicle Weight
1490
Place of Origin
Jiangsu, China
Brand Name
topall
Model Number
FCY20
Dimensions (L x W x H) (mm)
3058*1725*2360
Specifications
2 ton hydraulic site dumper jiangdong diesel dumper| Model | SD20(FY20) | ||||||||||
| Payload(kg) | 2000 | ||||||||||
| Capacity of bucket(m3) | 1 | ||||||||||
| Drive type | 4×2 | ||||||||||
| Max.speed(km/h) | 25 | ||||||||||
| Grade ability(%) | 21 | ||||||||||
| Min.turning radius(m) | ≤4 | ||||||||||
| Min ground clearance(mm) | ≥205 | ||||||||||
| Clutch | Constant-contact,single-disc,dry clutch | ||||||||||
| Tipping system | Hydraulic tipping hopper | ||||||||||
| Electric starting | Yes | ||||||||||
| Engine | model | JIANGDONG | |||||||||
| type | Twin cylinders, Water-cooling system with radiator | ||||||||||
| 12 hours rated power | 23.5kw/2600rpm | ||||||||||
| Overall size(mm) | 3058×1725×2360 | ||||||||||
| Weight(kg) | 1490 | ||||||||||
2 ton site dumper specification
