Auto/SY316 diesel hydraulic starting device
Auto/SY316 diesel hydraulic starting device
While no external energy (such as electric supply trouble), the user can operate the hydraulic starting device to start the diesel engine through the storage the continuously human energy.
The device has an advantage of simple operation, safety, reliability and can successfully start the engine in low ambient temperature area.
Manual/Automatic pressurized hydraulic starting device figure description
1,The hydraulic starting motor
2,Starting control valve
3,Manual hydraulic pump high pressure control valve
4,Pressure gauge
5,Pressure relief valve
6,Hydraulic pump
7, Air filter
8,The hydraulic oil tank assembly
9,Accumulator
10,AJF safety valve
Main Technical Data
Model |
SY316 |
Rated starting torque N·m |
32.2 |
Rated power kw |
6.5 |
Working pressure of accumulator Mpa |
16 |
Max. speed r/min |
3000 |
Nitrogen gas pressure of bladder accumulator Mpa |
8.5 |
Rated working pressure Mpa |
16 |
Hydraulic oil capacity L |
12 |
Working pressure of hydraulic hose Mpa |
16 |
Working pressure of low pressure hose Mpa |
10 |
