Specifications
concrete mixer is of middle capacity, self-falling type. It is suitable for mixing plastic and low-slump concrete.China famous brand concrete mixer
This concrete mixer is of middle capacity, self-falling type. It is suitable for mixing plastic and low-slump concrete. The aggregate size is required to be smaller than 60 mm.
The drum revolves for mixing and reverses for discharging. The rated output capacity of this mixer is 0.50 cubic meter.
And this mixer has new features:
1. It adds a water pump for water circulation between water tank of the engine and the radiator; keeps the engine water temperature to be stable.
2. Second, removing the air sucking point from the back to the front, reduce to suck the dust. It will be good to prolong the service life of the engine.
It has the advantages of compact structure, higher reliability, mixing evenly, big capacity, easy operation, easily movable between sites, etc. The mixer is widely used in building site, road and bridge project, and many other construction sites.
Main technical specification is
Model |
JZR500/RDCM500-16DH |
|
Type |
Self-falling |
|
Towing |
Four-towing wheels |
|
Capacity of loading |
750L |
|
Capacity of discharging |
500L |
|
Capacity of water tank |
140L |
|
Diesel engine |
Model |
YANMAR CY1115-XE
|
Power |
14.7kw |
|
Speed |
2200r/min |
|
Max towing speed |
20 km/h |
|
Max. Aggregate size |
60mm |
|
Output |
18 -22cubic meter/hour |
|
Hopper lifting model |
Hydraulic tipping hopper or hydraulic hoisting sliding hopper |
|
Tire |
6.50-16 |
|
4.00-8 | ||
Overall dimension(L×W×H) |
3750×2240×3800mm |
|
Total weight |
2250/2350kg |
|
