Advance Marine Gearbox T300 for Marine Engine
US$ 1,000 - 5,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
ADVANCE
Model Number:
T300
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or other ports in China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Advance Marine Gearbox T300-1 for Marine EngineUS$ 1,000 - 5,000MOQ: 1 Piece -
Advance Marine Gearbox MB270A for Marine EngineUS$ 1,000 - 5,000MOQ: 1 Piece
-
Advance Marine Gearbox MB242 for Marine EngineUS$ 1,000 - 5,000MOQ: 1 Piece
-
Advance Marine Gearbox MB170 for Marine EngineUS$ 1,000 - 5,000MOQ: 1 Piece
-
Advance Marine Gearbox MA142 for Marine EngineUS$ 1,000 - 5,000MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
ADVANCE
Model Number
T300
Gearing Arrangement
Planetary
Input Speed
1000-2300 r/min
Product Description
Marine Gearbox T300 possesses functions of speed reduction, ahead and astern clutching and bearing propeller thrust. It is designed of vertically offset and two-stage transmission, featuring in small in volume, larger in ratio, light in weight and convenient in dis- and reassembly and maintenance.
This product are approved by CCS, BV, GL, LR, ABS, NK, DNV, RS and KR Classification Societies.
Product Application
Marine Gearbox T300 is suitable for fishing, tug, and various engineering and transport boats.
Main Technical Data
| Input speed | 1000-2300r/min | ||
| Reduction ratio | 4.73,4.95,6.032,6.649,7.039 | Trans. capacity | 0.243kw/r/min |
| 7.543,8.02 | 0.221kw/r/min | ||
| 8.47 | 0.200kw/r/min | ||
| Control way | Push-and-pull flexible shaft, electrically, pneumatically | ||
| Rated thrust | 70KN | ||
| Center distance | 355mm | ||
| L×W×H | 772×980×1106mm | ||
| Net weight | 1120kg | ||
| Flywheel | SAE18,16,14 | ||
| Bell housing | SAE0,1 | ||
