For Fire Fighting System Control Panel With Addressable Function
US$ 1 - 500
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Asenware
Model Number:
AW-AFP2189
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2 Wire Communication Addressable Fire Alarm Control Panel With Extra Loop CardUS$ 1 - 1,200MOQ: 10 Pieces -
2 Wire Fire Alarm System Hot Products Fire Alarm Control Panel AddressableUS$ 1 - 500MOQ: 10 Pieces
-
Addressable Fire Alarm Control Panel With 324 Address for Smart Home SystemUS$ 1 - 500MOQ: 10 Pieces
-
Fire Alarm Addressable Control Panel for Access Control SystemUS$ 1 - 1,200MOQ: 10 Pieces
-
Wireless Addressable Fire Alarm Control Panel for Fire Fighting System Control PanelUS$ 1 - 1,200MOQ: 10 Pieces
Place of Origin
Guangdong, China
Brand Name
Asenware
Model Number
AW-AFP2189
For fire fighting system control panel with addressable function
Specification:
| Name | AW-AFP2189 fire alarm control panel |
| Model NO | AW-AFP2189 |
| AW-AFP2188 system capacity | 100/200/324 points (non-polarity, two wire bus, fully mixed coding) |
| AC input voltage | AC 220V±20% 50Hz |
| DC power |
DC24V 5.0Ah, two fully sealed maintenance-free DC12V 5.0Ah storage batteries connected in series |
| AC input power | 20W |
| Circuit bus | two-wire system |
| Total length | ≤1500m |
| Voltage UL of the circuit bus |
+20V≤UL≤+26V(when the DC power is operating) +24V≤UL≤+26V(when the AC power is operating) |
| System working conditions |
1. Temperature: -10°C~+50°C 2. Humidity: ≤95% 3. Power supply: AC 220V 50HZ ,DC 24V 6A 4. Output contact capacity: AC 220V 1A , DC 27.6V 3A |
Product pictures:
