Specifications
1. Test meter errors without disconnecting mains supply.2. Optional dummy load box
3. Certificate: ISO 9002
SH16 Portable Single Phase Energy Meter Test equipment at work site
Main Performance:
1. Inner setting programmed power source, scientific meter calibrator.
2. Current output: 060A, satisfying the calibration for different meters and more testing points.
3. The phase between the voltage on site and current output: 0359.9° shall be adjusted.
4. Measurement on site without disconnecting power circuit by current clamps.
5. Error, voltage, current, phase, frequency, and power factor can be tested directly.
6. LCD display, simple and easy operation interface.
7. Low power consumption, high accuracy and convenient and portable.
Index:
1.Accuracy class: 0.2, 0.3.
2.Phase scope: 0359.9°, adjusted resolution: 0.1°.
3.Current output scope: 060A, continually adjusting, detailed range: 1A, 5A, 20A, 60A.
4.Traceable city power frequency: 45.0065.00 HZ.
5.Power supply: 45.0065.00 HZ.; 220V±10%.
6..Power consumption: <=120VA.
7.Working circumstance:
temperature: 0-40°C, humidity:30%-80%RH.
Dimension: 406X330X174MM
We can make energy meter test bench according to your request.
1.Different kinds of meter positions.
2.Test bench or Portable test device.
3.Different accuracy class.
4.Whatever the figure of the energy meter is.
1. We can produce the single phase meter test bench/single phase energy meter instrument/single phase electricity meter test equipment according to client's requirement.
2. Good after-sale service, and good quality.
3. All our products can test all items such as Per IEC and ANSI
