LMZJ1-0.66KV Current Transformers
- 2000 Piece / Pieces per Month
- As per your request
- T/T
Product Details
Place of Origin: | Henan, China | Brand Name: | SMS | Model Number: | LMZJ1-0.66 |
Usage: | Current |
Product Description
Specifications
1. ISO 9001:2008 verified2. 18 years' manufacturer & supplier
3. Hot sale product
4. High quality with competitive price
LMZJ1-0.66KV Current Transformer
LMZ1-0.66kv Current Transformer is used for metering current and electric energy, protection in the electrical system of rated frequency 50HZ or 60HZ and rated voltage under 0.66KV.
Technical Data:
Primary Rated Current(A) | Secondary Rated Current(A) | Primary cable turns | Accuracy Class | Secondary Rated Output (VA) | Dimension | |
D | H | |||||
50 | 5 or 1 | 2 turn | 0.5 0.5S 0.2 0.2S | 5 | 30 (30) | 46 (65) |
75 | 5 or 10 | 30 (35) | 46 (55) | |||
100 | 1 turn | 5 or 10 | 30 (30) | 46 (65) | ||
150 | 5 or 10 | 30 (35) | 46 (55) | |||
200 | 5 or 10 | 30 (40) | 46 (50) | |||
300 | 5 or 10 | 30 (45) | 42 (50) | |||
400~600 | 5 or10 | 30 (45) | 42 (42) |
Contour Dimensions:
We can make various transformers as per your requests:
Contact Us
- SMS Electric Co., Ltd. Zhengzhou
- Contact nameSawyer Bai
- Phone0086-371-67391344
- AddressNo.85,the 5th Avenue,Economic & Technology Development Zone Zhengzhou,Henan
