Specifications
1.high quality hub reduction axle2.Established 1986 year
3.Professional technical team
4.Advanced Eauipments
13 ton hub reduction axle
Our main products are all kinds of truck axle, trailer axle,tractor axle and axle parts.
Advantages:
- The 13 ton hub reduction axle is customizalbe
- Established on 1986 year
- Professional technical team
- Advanced equipments
| LB300 Double reduction driving axle | ||
| Main technical parameters | ||
| Specifications | Middle axle parameters | Rear axle parameters |
| Payload (KG) | 13000/16000 | 13000/16000 |
| Maximum output torque (N.m) | 44000 | 44000 |
| Self-weight (KG) | 870 | 780 |
| Track (mm) | 1800-1860 | 1800-1860 |
| Spring pin distance (mm) | 960-1040 | 960-1040 |
| Selected ratio | 4.38;4.42;4.8;5.73;6.72;5.22;6.3 | 4.38;4.42;4.8;5.73;6.72;5.22;6.3 |
| Diameter of hub bolt distributed cicular (mm) | Φ335 | Φ335 |
| Brake specification-diameter(mm)*width(mm) | Φ420*185 | Φ420*185 |
| Suitable rim | 8.50-20 | 8.5-20 |
| Suitable tire | 12.00R20 | 12.00R20 |
| Minimum clearance to ground (mm) | 290 | 290 |
| LB300 Double reduction driving axle is developed as one of heavy-duty truck driving axle on the design basis of the Styer hub reduction axle,ABS and automatic gap adjusting arm can be optional. It can apply to highway trucks with 13T press-welding axle housing. It can apply to highway vehicles with 16T cast steel axle housing. | ||
|
3.5ton/4.5ton/5.5ton/6.5ton/ 7.5ton dis braked front axle assembly |
9 Ton front drum braked axle assembly
|
13 t dingle reduction driving axle for high power heavy duty truck
|
|
16t Single reduction driving axle ; China largest torque output: 60000 |
13 ton Single reduction tandem driving axle; Press welding housing and cast steel is optional
|
13ton or 16ton double reduction tandem driving axle 13 ton axle is press welding housing;16 ton is cast steel housing |
|
The bus axle has small noise and smooth brake , be used on 9-11m long bus |
32 ton suspension for heavy duty truck, engineering heavy truck
|
26 ton rear suspension assy for heavy duty engineering vehicle |
a
For more truck axle , please visit : https://img13.fr-trading.com/productgrouplist-222106055/Truck_Axle.html
Warranty
Shanghai YIWO will provide our clients a Claim Documents before cooperate.During the warranty period,
in case of material or workmanship has occurred with spare sparts in normal operation, the defective part
will be repaired or replaced free of charge, and the parts will be delivered with next batch goods.
Spare Parts
Shanghai YIWO will provide our clients a documents on axle parts before produce. And provide a
part price list for purchase.
Installation and Maintenance
Shanghai YIWO will provide Clients the instruction manual on installation and Maintenance.
If necessary, we will send technicist to site guidance.
Technical Service
We have strong after-sale technical service team to help you solve all problem during you use our products.
