wheel loader 968
- 3000 Unit / Units per Month
- qingdao
- T/T
You May Like
Product Details
| Condition | New | Brand Name | ZOT | |
| Model Number | 968 | Place of Origin | Shandong, China | |
| Type | Front Loader | Moving Type | Wheel Loader | |
| Dimension(Long * Breadth * High) | 7965*3050*3470mm | Rated Load | 6000KG | |
| Certification | CE GOST | Warranty | 1 year |
Product Description
Specifications
Wheel loader 6t, pilot control, joystick,6t wheel loader for saleShangchai engine Rated Power 175kw
Bucket Capacity 3.5m3
wheel loader 968
PHOTOS:
SPECIFICATIONS:
rated load | 6000KG | |
overall weight | 18200KG | |
rated bucket capacity | 3.8m3 | |
maximum tractive force | 158KN | |
maximum breakout force | 204KN | |
overall dimension (L×W×H) | 7965×3050×3470mm | |
maximum grade ability | 30°C | |
maximum dump height | 3448mm | |
maximum dump reach | 1249mm | |
minimum turning radius | 7020mm | |
model | DHD10G0245 | |
type | lnline water cooling dry cylinder injection | |
No. of cylinder-bore/stroke | 6-126×130mm | |
rated power | 175kw--2200r/min | |
maximum torque | 950N.m | |
min fuel-consume ratio | ≤220g/kw.h | |
torque converter | YJ375 | |
gearbox mode(WG180) | Planectary | |
gear shift | forward shift | 4 reverse shift |
maximum speed | 38km/h | |
:main reducing spiral | bevel gear grade 1reduction | |
decelerating mode | planetary reduction,grade 1 | |
wheel base (mm) | 3200mm | |
wheel tread | 2250mm | |
minimum ground clearance | 450mm | |
system working pressure | 17MPa | |
boom lifting time | 6.05+0.25s | |
total time | 10.8+0.5s | |
fuel tank capacity | 300L | |
function of leveling automatically | yes | |
service brake | air over hydraulic disc brake on 4 wheels | |
parking brake | manual parking brake | |
type specification | 26.5-25 | |
front tyre pressure | 0.4Mpa | |
rear tyre pressure | 0.35Mpa | |
