5t Wheel Loader SDLG
- T/T
You May Like
-
5t Wheel Loader SDLG 953
-
3.0t Wheel Loader SDLG
-
SDLG 3.0t Wheel Loader Yuchai YC6B125-T20 Engine
-
SDLG 2.6t Wheel Loader WEICHAI 47kw Engine, 265 Separate Double Change
-
Sdlg 2.0t Wheel Loader WEICHAI 43kw Engine, 3 + 2 Type Transmission
-
SDLG 1.8t Wheel Loader XICHAI 37kw Engine, ISUZU Heavy Weight Axles
Product Details
| Condition | New | Brand Name | ZOT | |
| Model Number | G956 | Place of Origin | Shandong, China | |
| Type | Front Loader | Moving Type | Wheel Loader | |
| Dimension(Long * Breadth * High) | 8020*3382*2800MM | Rated Load | 5000KG | |
| Certification | ISO | Warranty | 1 YEAR | |
| After-sales Service Provided | Overseas service center available |
Product Description
Specifications
Wheel Loader
Item | Specifications | |
Engine Model | SDEC C6121 | |
Rated Power | kw | 162 |
Rated Speed | r/min | 2200 |
Bucket Capacity | m3 | 3 |
Rated Load | kg | 5000 |
Traveling Speed | ||
Forward I | km/h | 0-7 |
Forward II | km/h | 0-12 |
Forward III | km/h | 0-23 |
Forward IV | km/h | 0-38 |
Reverse I | km/h | 0-7 |
Reverse II | km/h | 0-12 |
Reverse III | km/h | 0-23 |
Min. Turning Radius (outside of tyres) | mm | 6044 |
Level Passing Radius (outside of bucket) | mm | 6707 |
Max. Breakout Force | kn | ≥160±5 |
Max. Drawing Force | kn | ≥150±5 |
Max. Climbing Gradient | 30° | |
Rasing time (full load) | s | ≤6.5 |
Lowering time (empty bucket) | s | ≤3.5 |
The sum of three items | s | ≤11.5 |
Overall Length | mm | 8020 |
Overall Height | mm | 3382 |
Overall Width (Outside of wheel) | mm | 2800 |
Max. Dumping Height @45 | mm | 3120 |
Dumping reach @45 | mm | 1120 |
Bucket width | mm | 2988 |
Wheel Track | mm | 2248 |
Axle Base (Front/ Rear) | mm | 3200(1600/1600)mm |
Operating Weight | kg | 16800kg |
Axle No. | 2 | |
