Help CenterMotorhome TPMS, 18 Wheels Truck & Trailer Tire Pressure Monitoring System
Related Products
Specifications
Tire Pressure Monitoring System1.wireless TPMS
2.instant installation
3.Improve fuel saving
4.Extend tire life
1. Tire Pressure Monitoring System package information
- Monitor kit
- Relay & sensor kit
2. TD2000-X technical specification:
Transmitter:
- Frequency:315 MHz
- Pressure range:0-180 PSI
- Accuracy:Pressure ±3 PSI,temperature±2°C
- Operation temperature:- 40°C~125°C
- Dimensions:Diameter 20.5mm × Length 20mm
- Weight:10g(±1)
Monitor specification:
- Frequency:315MHz/433.92 MHz/2.4GHz
- Operation temperature:-20°C~80°C
- Dimensions: Length 102mm × width 72mm × height 29mm
- Weight:143g
Relay specification:
- Frequency:315MHz/433.92 MHz/2.4 GHz
- Operation temperature:-40°C~85°C
- Dimensions: Length 105mm × width 50mm × height 85mm
- Weight:200g
3. Product features:
DIY installation
Simply screw the sensors onto the valve stems in the place of valve stem caps.
Light and compact
Extremely lightweight and compact with specially designed electronic sensors.
Accurate tyre pressure sensors
Electronic tyre pressure sensors are accurate to +/- 1 PSI.
RoHS compliance
All components are complied with environmental protection requirements.
Abnormal pressure warming
The LCD monitor will send an immediate warning if any tyre is monitored and exceeds the pressure parameters that you chose to set.
Anti theft sensor mounting design
Each of the tyre pressure sensor is provided with a specially designed locknut. This secured it tightly onto the valve stem and prevents easy removal.
Transmission status display
The sensors will automatically transmit pressure/temperature date to the LCD monitor when it is turned on.
Biggest capacity tp support
Support up to 22 wheels in the 1 st version;36 wheels support is coming in the next version.
180 P.S.I
Truck sensor can support monitoring tyre preddure to 180 P.S.I
Auto switching process
Switching trailers without manual setting.
Battery power status display
The LCD monitor will display a low battery warming when either the monitor unit or any of the tyre sensors has low bettery power.
LCD monitor
The LCD monitor displays the 22 tyres pressures. This monitor can be mounted inside the vehicle by using either the suction cup mount or alternatively the self adhesive plate. This monitor can also be powered from the vehicle cigar lighter socket by using the power adapter supplied.
4. Other Series
5.Certificates
6.Welcome to visit my website:.tw/index.asp
