Clip on kitchen cabinet hinge

Specifications

1. soft-closing cabinet hinge
2.48 hours salt-srpay test
3.100000 times open-close SGS test
4.durable in use

1.Opening angle:175°

2.Depth of hinge cup:11.3mm

3.Cup diameter:35mm

4.Hole pitch: 45mm

5.Material:Steel cup nickel plated

6.Cup fixed: Wood screw #3.5*16mm;Dowels 8mm/10mm

7.Crank height:inset(c=19);half overlay(c=8);full overlay(c=0)

8.Hinge arm material thickness:1.0mm,1.2mm

9.Hinge arm screw: Slide on

10.plate height:H=2,H=4

11.Plate material thickness:1.0mm,1.2mm

12.Dimension of door:3-6mm

14. Certification:ISO9001

15.Test:SGS

16.Usage:cabinet

17.Finish: Nickel plated
