Beelee BL0211M G1/2" Brass Thermostatic Mixing Valve, Thermostatic Control Valve

Beelee BL0211M G1/2" Brass Thermostatic Mixing Valve, Thermostatic Control Valve thumbnail-1
Beelee BL0211M G1/2" Brass Thermostatic Mixing Valve, Thermostatic Control Valve thumbnail-2
Beelee BL0211M G1/2" Brass Thermostatic Mixing Valve, Thermostatic Control Valve thumbnail-3
Beelee BL0211M G1/2" Brass Thermostatic Mixing Valve, Thermostatic Control Valve thumbnail-4
Beelee BL0211M G1/2" Brass Thermostatic Mixing Valve, Thermostatic Control Valve thumbnail-5
Beelee BL0211M G1/2" Brass Thermostatic Mixing Valve, Thermostatic Control Valve photo-1
Beelee BL0211M G1/2" Brass Thermostatic Mixing Valve, Thermostatic Control Valve photo-2
Beelee BL0211M G1/2" Brass Thermostatic Mixing Valve, Thermostatic Control Valve photo-3
Beelee BL0211M G1/2" Brass Thermostatic Mixing Valve, Thermostatic Control Valve photo-4
Beelee BL0211M G1/2" Brass Thermostatic Mixing Valve, Thermostatic Control Valve photo-5
US$ 30.00 - 35.00 MOQ: 1 Piece
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Regulating
Pressure:
Medium Pressure
Contact Supplier Request Quote Chat Now
Wenzhou Bela Sanitary Ware Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Standard or Nonstandard Standard
Structure Regulating
Pressure Medium Pressure
Power Hydraulic
Material Brass
Temperature of Media Normal Temperature
Media Water
Port Size 1/2"
Place of Origin Zhejiang, China
Model Number BL0211M
Brand Name Beelee
Application Home Kitchen

Beelee BL0211M G1/2" Brass Thermostatic Mixing Valve, Thermostatic Control Valve


Thermostatic Mixing Valve Features:

1) Work Water Pressure: 0.05-1Mpa (Exceeding 0.5Mpa Recommend to install controlling of flow rate equipment)

2) Perfect Water Pressure: 0.05-0.5Mpa

3) Scope of Cold Water Temperature:5-29

4) Scope of Hot Water Temperature: 50-80

5) Scope of Adjustable Temperature: 20-50

6) Safety Temperature Key: 38

7) Result of Unavailable Cold Water: When exceeding 5seconds of unavailable cold

water, valve will control water flowing rate to 1.9Litre/Minute, volume of flowing

water ≤150ml, temperature of water≤49

8) Life of Valve:CSA B125-98 ASSE 1016 (more than 100,000 Cycles)

 Beelee BL0211M G1/2" Brass Thermostatic Mixing Valve, Thermostatic Control ValveBeelee BL0211M G1/2" Brass Thermostatic Mixing Valve, Thermostatic Control Valve

Product Name
Beelee Adjustable Temperature Thermostatic Mixing Valve for Solar System
Material
solid brass main body,Cu>=59%
Work Pressure
0.05Mpa—1Mpa
Ideal Pressure
0.1Mpa—0.5Mpa.Installation pressure release valve when exceed ideal pressure.
Standard Pressure
Dynamic pressure0.3±0.02Mpa.
Water Pressure Testing
1.6MPA
Air Pressure Testing
0.6MPA
Cold Water Supply Temperature
4-29°C
Hot Water Supply Temperature
55-85°C
Proposed Water Supply Temperature
55-70°C
Out Water Temperature Range
20-55°C
The Safety Temperature
38°C
Safety Characteristic
If cold water supply fails ,flow rate will be reduced to virtually shut off which avoid the risk of scalding.
Temperature accuracy
Kept constant ±2°C for the setting.
The Thickness Of Chrome Plating
Nickel>8um Chrome>0.2um



 Beelee BL0211M G1/2" Brass Thermostatic Mixing Valve, Thermostatic Control Valve

Quality Control:
1. Inspection of the casting
2. Leakage test after machining
3. Surface inspection after polishing
4. Surface inspection after plating
5. Leakage test in assembly
6. Measuping for the finished products

Our Capacity:
1) Date of foundation:2004
2) Annual Sales: US$10 Million - US$50 Million
3) About QC: Excellent & Responsible
4) Main Products: Basin Faucets, Kitchen Faucets, Shower Faucets, Bath Faucet,Bathroom Mirrors,Shower Head & Bathroom Accessories.

5) Main Market: Europe, South America, North America, Mid East, Oceania, etc.



Shipping
1. FedEx/DHL/UPS/TNT for samples, Door-to-Door;
2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;
3. Customers specifying freight forwarders or negotiable shipping methods.
4. Delivery Time: 3-7 days for samples; 5-30 days for batch goods.

Payment Terms
1. Payment: T/T, Western Union,PayPal; 30% deposits; 70% balance before delivery.
2. Warranty:3 years
