Backhoe Loader With Commins Engine

Name: Backhoe Loader With Commins Engine
Brand: SDLG
Availability: InStock

FOB Price

US$ 33,500 - 35,000 / Unit

1 Unit(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Brand Name	SDLG
Model Number	LGB680	Place of Origin	Shandong, China
Type	Backhoe Loader	Moving Type	Wheel Loader
Dimension(Long * Breadth * High)	757022363540mm	Rated Load	1800kg
Certification	GOST	Warranty	18months
After-sales Service Provided	Engineers available to service machinery overseas

1 Engine Commins
2 Bucket: 1m3
3 Axle: SDLG
4 Air condition, Pilot control optional

Backhoe loader with Commins Engine

1 SPECIFICATION

Loading bucket capacity	1.0 m³
Max digging force	≥44.4KN
Max breakout force	≥53.5KN
Max tractive force	≥60KN
Level passing radius	5225mm
Engine
Model	YC4B80-T10,cummins 4bt
Rated power	58KW,70kw
Rated speed	2400rpm
Fuel consumption ration	≤240g/Kw.h
Transmission system
Torque converter type	Single plase, single stage,3 elements
Torque ratio	3.7
Transmission type	Fixed shaft power shift
Gear shift	2 forward shift,2 reverse shift
Type	4-wheel drive

2 PHOTO IN FACTORY
