TPO Watetproof Membrane

Name: TPO Watetproof Membrane
Brand: hongyuan
SKU: 112461301
Availability: InStock

US$ 3 - 7 MOQ: 2000 Square Meters

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

hongyuan

Model Number:

HPM-T

Weifang Hongyuan Waterproof Materials Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name hongyuan

Model Number HPM-T

Specifications

1.TPO watetproof membrane
1.width:2.05m
2.length:20m
3.thickness:1.2mm,1.5mm,2mm
4.type: reinforced ,homogeneous

TPO watetproof membrane

Features

1.It’s easy to install with good system integrity, few accessories.

2. Excellent tensile strength, tearing resistance and penetration resistance performance.

3. No plasticizer. They have been tested as having excellent resistance to thermal aging and ultraviolet, durable and exposed.

4. Hot-air welding. The peel strength of joint is high.

5. Fast welding speed.

6. Environment friendly, 100% recycled, without chlorine.

7. Durable hot welding performance and easy to repair.

			Specification
			H	L	P		G	GL
The resin thickness of Middle fabric, mm≥			—		0.40
Maximum tension,N/cm ≥			—	200	250		—	200
Tension strength,Mpa≥			12				12
Maximum tension elongation,%≥					15
Fracture elongation,%≥			500	250			400	200
Heat treatment size change rate %≤			2.0	1.0	0.5		0.1	0.1
Low temperature bend			-40°C No crack
Water tightness			0.3Mpa,2h, No seepage
Attack resistance			0.5kg·m,No seepage
Static charge resistance			—			20kg ,No seepage
Seam strip strength ,N/mm≥			4.0 or Membranes break			3.0
Right-angle tear strength,N/mm≥			60				60
Trapezoid tear strength N≥			—	300		450		350
Bibulous rate (70°C 168h), %		After soaking≤	4.0
		Air-cure later≥	-0.40
Heat aging (115°C)	Time		672h
	Appearance		No blister,flaw,delamination,coherence,hole
	Tensile strength retention,%≥		90
	Elongation rate of keeping,%≥		90
	Low temperature bend		-40°C, No crack
Chemistry resistance	Appearance		No blister,flaw,delamination,coherence,hole
	Tensile strength retention,%≥		90
	Elongation rate of keeping,%≥		90
	Low-temperature bending		-40°C, No crack
Artificial weather accelerated aging	Time		1500hb
	Appearance		No blister,flaw,delamination,coherence,hole
	Tensile strength retention%≥		90
	Elongation rate of keeping%≥		90
	Low temperature bend		-40°C ,No crack
