wire length counter meter

Digital electric meter (Model:CCDD-60L)

CCDD series belt type counter will provide you with the industry's most accurate measurement. reduce your production costs. Electronic controller unit can do preset in length, alarm time, and a variety of customized signal output.

Features

1.Designed for wire and cable pipe meter and design process, high precision.

2.LED display is clear and easy reading.

3. Electronic controller unit provides multiple sets of relay output, easy to manage the production automatically .

4. High accuracy,up to +/- 0.1%

5. Positive or reverse two-way adjustable counting

6. Emergency power down data protection

7.CCDD-150L is specially designed with air cylinder unit.

8.Counter support height can be adjusted to adapt to different heights of the production line.

9. The position of decimal point on display is adjustable..

10. Standard Belt,easy to find replacement belt in market.

Specification

Model:CCDD-60L

The Electronic Counter
Maximum count: 10Km
Measurable length: 0-99999.99m
Cumulative length: 0-9999999m
Calibrate measuring precision.
Protection data when Power Down.
Pre-setting the length.
Pre-setting alarm length.
External dimensions: 160mm×80mm×170mm
Installation hole size: 152mm×76mm
