Wire meter counter (Model:CCDD-60L)
Technical parameters:
Model |
CCDD-30L |
CCDD-60L |
CCDD-150L |
Measuring Range |
3-30mm |
3-50mm |
3-150mm |
Max Counting Length |
9999999 |
999999 |
999999 |
Max Total Length |
0-99999.99 |
0-99999.99 |
0-99999.99 |
Accuracy |
+/- 0.1% |
+/- 0.1% |
+/- 0.1% |
Dimension |
410x180x1200mm |
430x225x1200mm |
490x370x590mm |
Total Net Weight |
17KG |
22KG |
55KG |
Max Measuring Speed |
400 m/min |
400 m/min |
400 m/min |
Relay Output |
2 |
2 |
2 |
Alarm Output |
Yes |
Yes |
Yes |
Display digits |
7 digit |
7 digit |
7 digit |
Length Measuring Unit |
Meter |
Meter |
Meter |
Calibration |
Yes |
Yes |
Yes |
Decimal Point Shift |
Yes |
Yes |
Yes |
Length Preset |
Yes |
Yes |
Yes |
Ahead of Preset Output |
Yes |
Yes |
Yes |
Control Preset |
Yes |
Yes |
Yes |
Emergent Data Protection |
Yes |
Yes |
Yes |
Two-Direction Counting |
Yes |
Yes |
Yes |
Ft Measuring Unit |
Option |
Option |
Option |
RS485 |
Option |
Option |
Option |
Power Consumption |
<10W |
<10W |
<10W |
Voltage |
220V 50/60HZ |
220V 50/60HZ |
220V 50/60HZ |
Model:CCDD-60L
The Electronic Counter
Maximum count: 10Km
Measurable length: 0-99999.99m
Cumulative length: 0-9999999m
Calibrate measuring precision.
Protection data when Power Down.
Pre-setting the length.
Pre-setting alarm length.
External dimensions: 160mm×80mm×170mm
Installation hole size: 152mm×76mm
