ATC CNC ENGRAVING MACHINE
Model Features:
1.Gantry machining center is specially designed for middle and-high-end clients with higher automation degree requirements. It’s suitable for high-volume, 24-hour processing non-metallic, copper, aluminum and aluminum extrusion profiles and so on.
2.High stability: Industrial production models, heavy-duty all-steel structure
welding, tempering vector effict processing, solid and uneasy deformation;
3.High-quality parts: Taiwan control system ,high-precision spindle ceramic
bearing , low noise, and long service life. Imported linear guide; German ball screw, big loading capacity, high precision for cutting; servo system, high pulling torque has improved the safety of systems engineering;
4.Modular structure design: elect various processing conversion head configuration, can carry on carving, engraving, cutting and milling work;
5.Easy and safe modes of operation: Advanced documents pre-processing functions ensure running speed and accuracy;
6.Row automatic tool changing system: 8 tools’ magazine capacity;
7.High adhesion vacuum suction device;
8.Software Compatibility: compatible with the processing code generated by a variety of CAD/CAM design softwares such as type3/artcam/castmate/Wentai
9.Improving oiling lubrication system extends the machine’s service life.
Applications:
1, Arts & Crafts industry:
Sculpture making of arts & crafts such as process relief, shadow carving, craft ornaments, car accessories and so on.
2, Furniture industry:
Solid wooden doors, composite doors, cabinet doors, interior doors, sofa legs, headboards, antique furniture and superficial flower-shaped engraving of various plate-type furniture and disposable finishing of process such as unlocking holes.
3, Mould industry:
Casting wooden molds, precisive making for disappeared mold casting foam, food molds (such as: moon cake molds).
4, Architectural model making
5, Advertising industry:
Engraving and making for acrylic cutting and engraving, acrylic plastic model making, badges and a variety of logo signs
6, Decorated industry:
Variety of decorations engraving process such as decorative murals, screens, decorative patterns, three-dimensional wave boards, sound-absorbing panels and so on.
7, Semi-finished products processing of industrial equipment accessories
Deep processing for semi-finished products such as countertops of industrial sewing mahines and electrical cabinets.
8, Musical instrument industry:
Headstock processing, guitar semi-finished products processing, surface sculpture and three-dimensional curved surface making of various musical instruments’ decorative patterns
Parts:
Parameters:
Machine Model |
FASTCUT-25H |
Working Area |
1300mm*2500mm*200mm(51’’* 98’’*8’’) |
Traverse Speed |
≥30000mm/min |
Spindle Power |
4.5KW various frequency spindle (or bigger power spindle) |
Spindle Rotating Speed |
24000rpm/min |
Spindle Cooling |
Air-cooling/water-cooling (or Italian HSD spindle) |
Magazine |
8 cutting tool positions in a row or bamboo hat-like magazine (3-12 positions are optional) |
Clamp Diameter |
3.175-12.7mm |
Mechanical Precision |
0.025mm |
Compatible Commands |
G-CODE, PLT, mmg, UG, ENG, HPGL and so on |
Main Power |
4KW |
Voltage |
AC380V/220V |
Whole Machine Size |
2100mm*3200mm*1950mm |
Net Weight |
1800KG |
Others |
Models with any processing areas can be customized. |
Samples:
Company Advantages:
1, Firstclass factory meets international production plant's standard, ten years' manufacture and export experiences
2, Own most advanced domestic cnc machining production equipments
3,20 professional high-end R&D technical staff, and can provide multiple languages and real-time online technical support
4,5-9 days machine production time, one year warranty and lifetime free maintenance
5,OEM and ODM services avaliable
6,Same quality, our price and service are better;Same price, our quality and service are better
7, with CE, FDA, SGS, ISO9000 certifications
Guarantee and After-sale Service:
1.One year guarantee for whole machine and six months for spindle
2.24 hours technical support by e-mail
3.Calling and door-to-door service
4.Use-friendly software and detailed specification
Our Company:
Production Procedure:
FAQ:
In order to help you choose the best suitable machine,can you reply my questions below, thank you.
Q1: What about your material , wood or acrylic or ?
Q2: The size of your material , length, width and thickness?
Q3: Do you want to cut or engrave your material ? Or both cut&engrave ?
Q4: What machining effect do you want to get ? It is better for me if you can send sample pictures to me .
Q5: The machine chooses 220v or 110v or ?
Q6: What is the nearest sea port to you?
