Universal Material Testing Machine

Name: Universal Material Testing Machine
Brand: Yuelian
SKU: 112426489
Availability: InStock

US$ 9,000 - 9,999 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Yuelian

Model Number:

YL-1123

Guangdong Yuelian Instruments Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Yuelian

Model Number YL-1123

Power Electronic

Usage Other, Universal Material Testing Machine

Universal Material Testing Machine YL-1123

Purpose:

This tester is designed for conduct tensile, compression, bending, shearing, bonding strength, peeling,

tearing and other tests for rubber, plastic, leather, metal, nylon line, fabric, paper, aviation, packaging,

construction, petrifaction, electrician, vehicle and other materials. It is a basic equipment of quality control,

receiving inspection, physical test, mechanics research, material development.

Software Function:

Test & Control System is designed for PC Electronic Universal Testing Machines, PC Hydraulic Universal

Testing Machines and PC Compression testers; can conduct tensile, compression, bending, shearing,

tearing and peeling test; use PC and interface board for data collection, preservation, processing and

printing test result; can calculate max force, yield strength, average peeling force, max deformation, yield

point, elastic modulus and other parameters; can conduct curve graphics processing, multi-sensor support,

video and image interface, flexible data processing, MS-ACCESS database support, making more powerful

function of system.

Specification:

Capacity	1, 2, 5, 10, 20, 50, 100, 200, 500, 1000, 2000 kg (can select double capacities preparation)
Display	Computer display mode
Force Resolution	1/250,000
Force Accuracy	≤±0.5%
Stroke Resolution	0.0001mm
Control Mode	All computerized operation mode
Test Stroke	1000mm
Test Width	420mm
Test Speed	0.001~500mm/min, can set by computer, with up & down fast adjustment button of grips
Force Unit Switch	Kgf, N, Ibf, g, ton, Mpa
Stop Mode	Overload stop, emergency stop button, specimen damage automatic stop, upper & lower limit set automatic stop, automatic reset function
Machine Dimension	72×52×130cm(W×D×H)
Machine Drive	Servo motor drive, synchronous wheel and precision ball screw drive
Power	400W
Machine Weight	Approx 115kg
Power Supply	220V 50/60HZ 10A
Standard Device	1 set of grips, computer software, USB computer connection wire
Optional	Personal computer
