Specifications
compression resistance intensity tester* peel,tear test
* rubber,plastic,metal test
* 650mm stroke
* CE certificate
YL-1109 compression resistance intensity tester
This tester is designed for conduct tensile, compression, bending, shearing, bending strength, peeling, tearing and other tests for rubber, plastic, leather, metal, nylon line, fabric, paper, aviation, packaging, construction, petrifaction, electrician, vehicle and other materials. It is a basic equipment of quality control, receiving inspection, physical test, mechanics research, material development.
Characteristics:
Capacity |
1,2,5,10,20kgs |
Unit Switch |
kgf , lbf, N , kN |
Testing Item |
compression resistance intensity, compression resistance deformation, constant compression (pulling) testing, tearing strength, tensile strength. |
Testing Accuracy |
<±0.1%; |
Force Resolution |
1/10,000 |
Valid Range of Strength Test |
1~100%F.S |
Deformation Value Accuracy |
Precede±1.0% |
Range of Speed test |
50~600mm/min, Available Set Free |
Test Stroke |
650mm without grip |
Test Space |
140mm |
Force Unit Switch |
kgf,gf ,N,kN,Ibf |
Stress Unit Switch |
MPa,kKPa,kgf/cm2,Ibf/in2 |
Deformation Unit Switch |
mm,cm,in |
Stop Mode |
Upper & lower limit security setting, emergency stop button, force & stretching setting, specimen damage sensor |
Machine Weight |
Approx 55kg |
Motor |
DC motor |
Power |
1PH,AC220V,50/60Hz,10A or specify |
Test Report
Workshop
Exhibition
Certification
