YL-1163 temperature and humidity control cabinet
Usage:temperature&humidity tensile testing machine is specially improved from the tensile testing machine to adopt to the temperature&humidity tensile test, available to do tensile, compression, bending, shearing, adhesive strength, bending strength, peeling, tearing and other tests for materials under different temperature&humidity conditions.To remove the temperature&humidity chamber when the room temperature test is required. It is convenient to add test space.
Software function:
Test & Control System is designed for PC Electronic Universal Testing Machines, PC Hydraulic Universal Testing Machines and PC Compression testers; can conduct tensile, compression, bending, shearing, tearing and peeling test; use PC and interface board for data collection, preservation, processing and printing test result; can calculate max force, yield strength, average peeling force, max deformation, yield point, elastic modulus and other parameters; can conduct curve graphics processing, multi-sensor support, video and image interface, flexible data processing, MS-ACCESS database support, making more powerful function of system.
Specification:
Capacity | 10N, 20N, 50N, 100N, 200N, 500N, 1KN, 2KN, 5KN, 10KN(can select double capacities preparation) |
Temp. Range | 0, -20, -40, -60, -70°C~150°C |
Humidity Range&accuracy | 20%~98%RH0.1%RH display |
Display | All computer display mode or LCD displayer |
Force Resolution | 1/250,000 |
Force Accuracy | ≤±0.5% |
Stroke Resolution | 0.005mm |
Control Mode | Tensile testing machine: all computer control mode or LCD control mode |
Temperature control | PID automatic calculation, steady state error |
Display accuracy | 0.1°C |
Temperature accuracy | ±1°C |
Programmable Mode | Independent research and development YL-C201 programmable controller, Chinese-English switch, touch control type colorful screen, 120 groups program memory, 1200 section program, 999 program cycles, 99 times each groups, time setting in 0-99H59M, available to connect to computer for the supervision program; |
Cycling system | Fan forcedcirculationsystemv |
Humidity Stability | ±2.5%RH |
Humidification System | Surface evaporative type, enclose protection of hydropenia, interrupt of power supply and superheat for humidifier. |
Dehumidification System | Frozen & latent heat dehumidification method |
Heating System | SUS304, stainless steel heater |
Cooling System | fan heat dissipation type, high efficiency compressor, environmental protection coolants |
Safety Device | Leakage and overload protection, compressor overload protection, the humidifier overheating protection, temperature limit protection device; |
Materials | SUS#304 stainless steel |
Test Stroke | 1200mm(tensile testing machine can be also used independently without the chamber) |
Test Width | 600mm(ensile testing machine can be also used independently without the chamber) |
Test chamber space | 40×80×40cm(W×D×H)(available to made according to the requirements) |
Test Speed | 0.5~500mm/min, set by computer, with up & downfast adjustment button of grips |
Force Unit Switch | kgf, N, Ibf, g, ton, Mpa |
Stop Mode | Overload stop, emergency stop button, specimen damage automatic stop, upper & lower limit set automatic stop, automatic reset function |
Machine Dimension | 130×150×210cm(W×D×H) |
Machine Drive | Servo motor drive, synchronous wheel and precision ball screw drive |
Power | 400W |
Machine Weight | Approx 450kg |
Power Supply | 220V 50/60HZ 30A |
Standard Device | grips extension rod, heat sink, a set of grip, computer software, USB computer connection wire; |
