Specifications
1. Fuel pump with high quality and competive price2. Use for Weichai engine
3. Ceritificate:ISO 9001:2008
Factory direct sales P series, PQ series, PZ series, PS7100 series, PS8500 series, P9 series, PA series, PM series, AD series, electronic VE pump, electronic unit pump, High-pressure common-rail fuel pump.
Suitable for Xichai, Dachai, Weichai, Cummins, Chaochai, Yuchai, Shangchai, Perkins, Foton, Zichai, Yangdong, Changchai, Laidong engine and so on.
Name of product | Fuel injection pump assembly |
Assembly code | CB6P826 |
Ordering code | VG1560080021 |
Suitable engine | Weichai WD615.87 |
Main technical pramenters
Main technical paramenters of fuel injection pump | |||||||
Paramenters series | PM | PM-2 | PA | P P3000 | PS7100 | PS8500 | P9 |
number of pump elements | 4 6 | 4 6 | 4 6 | 4 6 8 12 | 4 6 8 12 | 4 6 8 12 | 4 6 8 |
plunger diameter(mm) | 8 10 | 9 10.5 | 9 12 | 10 13 | 10 13 | 10 13 | 14 18 |
camshaft lift(mm) | 9 10 | 10 11 | 10 11 12 | 10 11 | 12 | 14 | 15 |
maximum supply of fuel(mm3/st) | 150 | 150 | 230 | 350 | 350 | 350 | 450 |
Allowing revolution(r/min) | 1800 | 1800 | 1600 | 1400 | 1300 | 1300 | 1000 |
maximum pressure(Mpa) | 90 | 106 | 100 | 85 | 120 | 120 | 100 |
Weight(Kg) | 10 | 10 | 16-20 | 23-40 | 22-35 | 22-35 | 35-75 |
center distance of cylinder(mm) | 26 | 28 | 32 | 35 | 35 | 35 | 45 |
The use of fuel-injection pump for attention
The fuel injectiion pump is the important buildup component of diesel engine, is made up of many delicate spare parts. Any incorrect use and carelessness can effect the normal work and useful life, and endanger the functions and reliability of engine, even occurr serious accident. So it must pay attention in use.
1. Before use, please confirm the assembly code of fuel pump.
2. Opening the timing cover plate cap and confirming the jaws of slot outwards. Clean the grease, take off the tapped plugs of governor and inject the engine oil.
3. It must use the clean diesel, 72 hours precipition treatment before use, inject fuel with clean container.
4. Installation and connection should keep to technical requirements of diesel engine installation. The connection should be fastened, no leakage in pipe system.
5. Adjust the fuel injection pump advanced angle according to the requirement of diesel engine.
6. Regular maintenance, keep in good condition, reduce engine trouble.
7. Remove the dirt, sediment and residual oil and inject the rust-preventative oil before long term storage.
Contact us
As the models of fuel pump are very large, we can’t show all of them. If what you need the fuel pump can’t find in our website, you can contact me directly.
