1200kw natural gas generator
Based on Jichai 190 engine
Jichai engine-12V190
Every generator set is subjected to a comprehensivetest program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;
24V DC start motor;
Equipped with battery charger and 24V highperformance maintenance-free lead-acid startingbatteries and connecting with cables;
Equipped with industrial silencer and flexible exhaust hose;
Equipped with CHINT MCCB circuit breaker;
Designed to Comply with ISO8528/GB2820;
Powered by Jichai engine,Controlled by Deepsea panel
Main Specification of Genset | |
Model of genset | ST-N1200GF |
Model of engine | H16V190ZLT-2 |
Model of alternator | 1FC6 564-6LA42 |
Coupling method | Elastic coupling |
Rated speed(r/min) | 1000 |
Rated power(kW/KVA) | 1200/1500 |
Rated voltage(V) | 415/240 |
Rated current(A) | 2087 |
Rated frequency(Hz) | 50 |
Rated power factor | 0.8 lagging |
Voltage regulation | Automatic |
Supply connecting | 3 phase 4 wire |
Governor | EGS-02 electric governor (WOODWARD) |
Control model | Remote electric control, Hand control |
Starting method | 24V DC electric starting motor |
Cooling method | Water cooling system |
Electrical efficiency | 38% |
Heat Consumption | ≤9500kJ/kWh |
Net weight(kg) | 24000 |
The control module gives digital readouts of:
Generator voltage;
Output frequency;
Engine speed;
Battery voltage;
Engine hours run.
The control module has indicators for failure
information:
Overspeed/underspeed,
Emergency stop
Low oil pressure;
High water temperature
Failure to start
Battery charger failure
Automatic shutdown occurs under:
Low engine oil pressure;
High engine water temperature;
Overspeed/underspeed;
Failure to start after three attempts.
With Cummins engine natural gas generator
Powered by Jichai 190 engine
