Automatic 400Kva Deutz Generator, Powered by Deutz BF6M1015C-LA G Engine

Name: Automatic 400Kva Deutz Generator, Powered by Deutz BF6M1015C-LA G Engine
Brand: Deutz
SKU: 112387981
Availability: InStock

Taizhou Sutech Power Machinery Co., Ltd.

Automatic 400Kva Deutz Generator, Powered by Deutz BF6M1015C-LA G Engine thumbnail-1

Automatic 400Kva Deutz Generator, Powered by Deutz BF6M1015C-LA G Engine photo-1

US$ 30,000 - 35,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Brand Name:

Deutz

Model Number:

400Kva Deutz generator

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Brand Name Deutz

Model Number 400Kva Deutz generator

Output Type AC Three Phase

Speed 1500rpm/min

Frequency 50Hz

Rated Power 400Kva

Rated Voltage 380/220V

Rated Current 576A

Specifications

400Kva Deutz generator, powered by Deutz BF6M1015C-LA G engine
Stamford alterantor
Deepsea control panel
High quality

400Kva Deutz generator (BF6M1015C-LA G)

Main technical data

Every generator set is subjected to a comprehensivetest program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;

24V DC start motor;

Equipped with battery charger and 24V highperformance maintenance-free lead-acid startingbatteries and connecting with cables;

Equipped with industrial silencer and flexible exhaust hose;

Equipped with CHINT MCCB circuit breaker;

Designed to Comply with ISO8528/GB2820;

Powered by Deutz engine,Controlled by Deepsea panel

Voltage

Phase

P.F

(COS)

Output

(KVA)

400/230V

0.8

400

Remark

60Hz, 220, 380V, 460V, 480V, 600V can be produced as requirements.

Engine

400Kva Deutz diesel generator engine data

Engine Model	BF6M1015C-LA G
Number of Cylinders	6 cylinders
Cylinder arrangement	Vertical in line
Cycle	4 stroke
Aspiration	Turbocharged and after water cooled
Bore×Stroke	132mm x145mm
Displacement	11.906L
Compression ratio	16.5:1
Prime Power/Speed	328KW / 1500rpm
Standby Power/Speed	365KW / 1500rpm
Speed Governor	Electrical
Cooling System	Forced water cooling cycle
Steady speed droop	≤1%
Total lubrication system capacity	36L
Coolant capacity (engine only)	17L
Fuel Consumption at 100% Load	84.0L
Fuel Consumption at 75% Load	60.6L
Starter Motor	DC24V,
Alternator	AC24V

Alternator

Alternator brand	Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII…
Prime power	400Kva
Frequency/speed	50HZ/1500rpm (60Hz/1800rpm)
Exciter type	Single bearing, Brushless, Self-excited
Power factor	0.8
Voltage adjust range	≥5%
Voltage regulation NL-FL	≤±1%
Insulation Grade	H
Protection Grade	IP23
