Containerized or Open Type 1250kva Silent Diesel Generator Powered by UK Original Perkin Engine 4012-46TWG2A

Name: Containerized or Open Type 1250kva Silent Diesel Generator Powered by UK Original Perkin Engine 4012-46TWG2A
Brand: 1000Kva 4012-46TWG2A generator
SKU: 112385795
Availability: InStock

Taizhou Sutech Power Machinery Co., Ltd.

Containerized or Open Type 1250kva Silent Diesel Generator Powered by UK Original Perkin Engine 4012-46TWG2A thumbnail-1

Containerized or Open Type 1250kva Silent Diesel Generator Powered by UK Original Perkin Engine 4012-46TWG2A photo-1

US$ 5,000 - 300,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Brand Name:

1000Kva 4012-46TWG2A generator

Model Number:

4012-46TWG2A

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Brand Name 1000Kva 4012-46TWG2A generator

Model Number 4012-46TWG2A

Output Type AC Three Phase

Speed 1500rpm/min

Frequency 50Hz

Rated Power 1250Kva

Rated Voltage 380/220V

Rated Current 1800A

1250Kva 4012-46TW2A diesel electric generator

Main technical data

UKP engine

Every generator set is subjected to a comprehensivetest program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;

24V DC start motor;

Equipped with battery charger and 24V highperformance maintenance-free lead-acid startingbatteries and connecting with cables;

Equipped with industrial silencer and flexible exhaust hose;

Equipped with CHINT MCCB circuit breaker;

Designed to Comply with ISO8528/GB2820;

Powered by UKP engine,Controlled by Deepsea panel

Voltage

Phase

P.F

(COS)

Output

(KVA)

400/230V

0.8

1250

Remark

60Hz, 220, 380V, 460V, 480V, 600V can be produced as requirements.

Engine

Engine Model	4012-46TWG2A
Number of Cylinders	12 cylinders, 60°Vee
Cycle	4 stroke
Aspiration	Turbocharged and after water cooled
Bore×Stroke	160mm x190mm
Displacement	45.842L
Compression ratio	13.6:1
Prime Power/Speed	1055KW / 1500rpm
Standby Power/Speed	1166KW / 1500rpm
Speed Governor	Electrical
Cooling System	Forced water cooling cycle
Steady speed droop	≤1%
Total lubrication system capacity	177L
Coolant capacity	201L
Fuel Consumption at 100% Load	212g/kw.h
Starter Motor	DC24V,
Alternator	DC24V

Alternator

Alternator brand	Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII…
Prime power	1250KVA
Frequency/speed	50HZ/1500rpm (60Hz/1800rpm)
Exciter type	Single bearing, Brushless, Self-excited
Power factor	0.8
Voltage adjust range	≥5%
Voltage regulation NL-FL	≤±1%
Insulation Grade	H
Protection Grade	IP23
Phase / wire	3 phase 4 wires
