Home > Products > 200Kw/250kva~400Kw/500Kva diesel generators > Silent and Rainproof 400kva Power Generator Powered by Cummins NTA855-G4 Engine

Silent and Rainproof 400kva Power Generator Powered by Cummins NTA855-G4 Engine

Name: Silent and Rainproof 400kva Power Generator Powered by Cummins NTA855-G4 Engine
Brand: NTA855-G4
Availability: InStock

FOB Price

US$ 15,000 - 25,500 / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	NTA855-G4
Model Number	Genset 400 kva	Output Type	AC Three Phase
Speed	1500rpm/min	Frequency	50Hz
Rated Power	400Kva	Rated Voltage	380/220V
Rated Current	576A

Product Description

400Kva Power Generator with Cummins engine

(Engine model: NTA855-G4)

Main technical data

Cummins engine-NTA855-G4

Every generator set is subjected to a comprehensivetest program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;

24V DC start motor;

Equipped with battery charger and 24V highperformance maintenance-free lead-acid startingbatteries and connecting with cables;

Equipped with industrial silencer and flexible exhaust hose;

Equipped with CHINT MCCB circuit breaker;

Designed to Comply with ISO8528/GB2820;

Powered by Cummins engine,Controlled by Deepsea panel

Voltage

Phase

P.F

(COS)

Output

(KVA)

400/230V

0.8

400

Remark

60Hz, 220, 380V, 460V, 480V, 600V can be produced as requirements.

Engine

Cummins 400kva diesel generator engine data

Engine Model	NTA855-G4
Number of Cylinders	6 cylinders, vertical in line
Cycle	4 stroke
Aspiration	Turbocharged and after water cooled
Bore×Stroke	140mm x152mm
Displacement	14L
Compression ratio	14.0:1
Standby Power/Speed	371KW / 1500rpm
Speed Governor	electrical
Cooling System	Forced water cooling cycle
Steady speed droop	≤1%
Total lubrication system capacity	38.6L
Coolant capacity (engine only)	20.6 L
Fuel Consumption at 100% Load	196 g/kw.h
Starter Motor	DC24V,
Alternator	DC24V

Alternator

Alternator brand	Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII…
Prime power	400Kva
Frequency/speed	50HZ/1500rpm (60Hz/1800rpm)
Exciter type	Single bearing, Brushless, Self-excited
Power factor	0.8
Voltage adjust range	≥5%
Voltage regulation NL-FL	≤±1%
Insulation Grade	H
Protection Grade	IP23

Control panel

The control module gives digital readouts of:

Generator voltage;

Output frequency;

Engine speed;

Battery voltage;

Engine hours run.

The control module has indicators for failure

information:

Overspeed/underspeed,

Emergency stop

Low oil pressure;

High water temperature

Failure to start

Battery charger failure

Automatic shutdown occurs under:

Low engine oil pressure;

High engine water temperature;

Overspeed/underspeed;

Failure to start after three attempts.

Pictures FYI

400Kva Cummins diesel generator

400Kva Cummins diesel generator (Testing)

400Kva Cummins diesel generator (Silent)

400Kva Cummins diesel generator (Shipping)
