Vegetable Juice Evaporator

Vegetable Juice Evaporator photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
KEWEI
Payment & Shipping
Payment Methods:
Port of Shipment:
ShangHai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Jiangsu, China
Brand Name KEWEI
Model Number FZG-15A
Type Other, concentrating boiler
After-sales Service Provided Engineers available to service machinery overseas

vegetable juice evaporator



It is applicable to vacuum concentration of heat sensitive materials

The equipment is a single-effect clearance type vacuum concentrating device,which is composed of vessel,heater,separator,hydraulic injector,blender and multistage pump etc.It is applicable to vacuum concentration of heat sensitive materials(such as fruit jam and fruit pulp etc. materials with bad fluidity) under low temperature.It has such features as small volume,simple structure,convenient operation,cleaning and maintenance.Parts that contact materials are made of SUS304 stainless steel.

Evaporating temperature: 50~55

Steam pressure ≤ 0.15Mpa

Type: jacket blending type

Vacuum degree: -0.083-0.0906Mpavegetable juice evaporatorvegetable juice evaporatorvegetable juice evaporator

Model

Evaporation

Circulating water consumption

Steam consumption

Total capacity installed

Heat exchange

Outline dimensions(m)

JNS-300

300L/h

12m3/h

240kg/h

7.0kw

24r/min

2.6x2.06x3.66

JNS-500

500L/h

19.3m3/h

560kg/h

9kw

24r/min

2.8x2.1x4.41

JNS-1000

1000L/h

39m3/h

1130kg/h

12.5kw

24r/min

3.0x2.2x4.5

vegetable juice evaporator
