The VIP is short for vacuum insulation plates. Because of its super heat-proof
quality, long useing life and excellent combination property, VIP has been used
in the refrigerator and freezer field, and now start in the construction field.
Our company's vacuum thermal insulation plates (hereinafter referred to as VIP),
is the new development on the super insulation material in recent years. Its coefficient
of thermal conductivity is just 0.003-0.006 W/MK, compared with the traditional
heat insulation materials, insulating VIP can meet the same thermal insulation
technology requirement, and at the same time its thin layer, small volume, light
weight and other advantages let VIP apply to refrigerators, deep freezers and
refrigerator, submarines, spacecraft, satellite and other fields for high energy
requirements, light weight and little space requirements for heat preservation
material.
Structure of vacuum insulation board is composite of the core material, the diaphragm and getter, etc.
1, Comparison of coefficient of thermal conductivity with other insulation materials
Matetrial |
VIP |
PU |
XPS |
EPS |
Coefficient of thermal conductivity (mw/m.k) |
6 |
24 |
30 |
41 |
2, Comparison of index of fireproofing with other insulation materials
Material |
VIP |
PU |
XPS |
EPS |
Fireproofing level |
A |
B2 |
B2 |
B2 |
3, The unit mass is very light, after construction and installation it is safety and hard to fall off.
4, The heat preservation, decoration engineering organic combine, than traditional insulation
system construction process the more simple
5, Construction is convenient, like ceramic tile can be pasted straight forward, greatly shorten
the construction period and save the cost.
6, Heat insulator material for inorganic heat preservation material, not burning fire prevention.
7, Non-toxic, green environmental protection and long service life.
