Professional Automatic PET PVC BOPP Self Adhesive Coating Machine price
Detailed Product Description
The machine is produced with international advanced coating technology, integrated with our many years of experiences in manufacturing coating machine. It is suitable for manufacturing hot stamping film, laser film, gold and silver paperboard which need coating and laminating.
Performance and characteristics:
1) It is provided with stepless speed regulation cylinder of American Emersion frequency converter, realizing synchronous speed regulation of drawing roller with anliox roller, with advantage of accurate, sensible, anti-jamming
2) It is provided with anliox roller plus blade for coating mode, and also provided with many selection opportunities of anilox roller with various coating amount
3) Moveable blade device
4) It is provided with separate five-section type constant temperature drying systemizing infrared stainless steel heating tube plus beating wind, as well as adjustable interior circulation air draining and suction devices. It is advantageous in strong wind-exit and wind-entrance, helping drying thoroughly
5) Gluing roller in oven will synchronously rotates with main shaft
6) Solenoid operated valve controlling is adopted for anilox roller and drawing roller
7) Automatic meter-measuring devices.
8) Key mode air shaft is used for unwinding and rewinding shafts, easy to load and unload
9) The oven adopts to close pressing by pneumatic
10) Gelatinizing, towing, rolling are controlled synchronous by three motors
Main technical parameter: | ||
Model of Machine | THV-A800 | THV-A1100 |
Width Coating | 800mm | 1100mm |
Max.Diameter of Releasing | φ800mm | φ800mm |
Max. Diameter of Rolling | φ800mm | φ800mm |
Temperature of Oven | 50-180 | 50-180 |
Speed of Coating | 50-90m/min | 50-90m/min |
Heating Way | Heating by electricity or wind oven | Heating by electricity or wind oven |
Total Power | 45kw | 55kw |
Weight | 6.0T | 8.0T |
Over all Dimesion | 15000×1800×3750mm | 15000×2100×3750mm |
