Specifications
Multifunctional Coating and Laminating Machine:The machine is produced with international advanced coating technology .Name:Multifunctional Coating and laminating Machine(THVF Series)
USE:
The machine is produced with international advanced coating technology integrated with our many years of experiences in manufacturing coating machine.It is suitable for manufaturing sticker, adhesive tape hot stamping film, laser film, gold and silver paperboard which need coating and laminating.
Performance and Characteristics:
1.It is provided with stepless speed regulation cylinder of American Emerson frequency converter, realizing synchronous speed regulation of drawing roller with anilox roller.With advantage of accurate, sensible, anti-jamming.
2.It is provided with anilox roller plus blade for coating mode, and also provided with many selection opportunities of anilox roller with various coating amount.
3.Moveable blade device.
4.It is provided with separaet five-section type constant temperature drying system using semiconductor tube plus heating wind, as well as adjiustable interior circulation air draining and suction devices.It is advantageous in strong wind-exit and wind entrance, helping dring thoroughty.
5.Guiding roller in oven will synchronously rotates with main shaft.
6.Solenoid operated valve controllin is adopted for anilox reller and drawing roller.
7.Automatic meter-measuring devices.
8.Key mode air shaft is used for unwinding and rewinding shafts, easy to load and unload.
9.Comma blade tand adopt pneumatic pressing
Main Technical Parameter:
Model |
Width Coating |
Max.Diameter of Releasing |
Max.Diameter of Rolling |
Temperature of oven |
Speed of Way |
Heating of Way |
Total Power |
Weight |
Overall Dimension |
THV-F800 |
800mm |
ø800mm |
ø800mm |
50-160ºC |
50-90m/min |
Heat by electric or hot-blast stove |
45kw |
6.5t |
15000×1800×3750mm |
THV-F1100 |
1100mm |
ø800mm |
ø800mm |
50-160ºC |
50-90m/min |
Heat by electric or hot-blast stove |
55kw |
8.0t |
15000×2100×3750mm |
