Glass Reinforced Plastic Pipe Continuous Winding Production Line
US$ 1,000,000 - 3,000,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Pipe Production Line
Pipe Material:
Other, glass fibre, resin
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CFW GRP Winding Pipe Line DGL-3000US$ 15,000,000 - 18,000,000MOQ: 1 Set -
Continuous Filament Winding Pipe LineUS$ 15,000,000 - 18,000,000MOQ: 1 Set
-
CFW Pipe MachineUS$ 15,000,000 - 18,000,000MOQ: 1 Set
-
GRP Coupling Sleeve MachineUS$ 500,000 - 950,000MOQ: 1 Set
-
GRP Pipe Hydraulic TesterUS$ 1,200,000 - 1,690,000MOQ: 1 Set
Condition
New
Type
Pipe Production Line
Pipe Material
Other, glass fibre, resin
Application
Energy Supply Pipe
Place of Origin
Shandong, China
Brand Name
LONGTECH
Model Number
DGL-1600/2600/3000
Voltage
380V
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
GRP production line of our company adopts continuous production technology which has a lot of features.One kind Continuous Wingding automatic production line is made up of winding--feeding--solidify--holding--anti-distortion--cutting and unloading system. This line with features as blew: high technology, high automatic level, high efficiency and more specifications. This continuous winding technology is the most advanced in the world and held one part in domestic. GRP Continuous Wingding automatic production line is made by Langtong Company, which hold totally independency knowledge property rights.
Continuous winding technology
Continuous Winding technology used for GRP pipes and tank’s production and mainly removed one glass fiber mixture layer to one moving steel belt mould. The mould made by one continuous steel belt winding on one horizontal mandrel and another inner layer film winding on mould. Then the resin mixture (direct yarn, cutting yarn, quartz sand and polyester etc.) will spray on mould well-proportioned and last surface yarn winding and solidify and then cutting on line and surface planning finished.
General Data:
Winding--Feeding--Solidif--Holding--Anti-distortio--Cutting--Unloading system.
Main technical data of GRP pipe line:
Model |
Pipe Range |
Power |
Producing Speed |
DGL-1600 |
600-1600 |
160kw |
8-22m/h |
DGL-2600 |
800-2600 |
180kw |
5-20m/h |
DGL-3000 |
800-3000 |
205kw |
4-20m/h |
