SINOTRUK HOWO water truck back spill and side spout function water curtain nozzle fire nozzle sprinkler
| |
Model Name |
SINOTRUK HOWO water truck 12000L |
Driving Type |
4*2,left hand drive |
Chassis model |
ZZ1167M4617C |
Weights | |
Rated payload weight(kg) |
20000 |
Curb weight(kg) |
8300 |
Dimensions | |
Wheelbase(mm) |
4600 |
Overall Dimension(mm) |
8500×2500×3300 |
Water tanker size |
12000L |
Max speed(km/h) |
90 |
Engine | |
Engine model |
WD615 (266HP) |
Engine type |
4 stroke water-cooled,turbo-charge,Intercooling engine |
No. of cylinders |
straight-6 cylinders |
Displacement(L) |
9.726L |
Max. output (kw) |
196kw |
Drive Line | |
Transmission |
HW13710CL,10forwarder,2 reverse gear,manual operation |
Steering |
ZF8098 |
Brake system |
Air brake |
Cab | |
Cab |
HW76 ,Full steel skeleton structure, covered with double layer steel plate;Can be tipped forwardly; with A/C;shock-absorbers Whole instrument desk, digital meters,ABS |
Standard configuration |
USB ,sound,electric windows,and so on |
Axle | |
Front axle |
HF7 |
Rear axle |
HCY13 |
Tire specification | |
Tire specification |
11.00-20 standard tire,10 tires+1 spare tire |
Specification fuction of water truck | |
Tanker body size |
Tank capacity: 12000L |
Tanker material |
Q235,carbon steel |
ntroduction |
1. Suction≥7m Sprinkler width≥14m Range≥28m 2. with front spout, back spill and side spout function 3. with the working platform at the back, wich can be installed green high-pressure water spray gun.(The spray gun shape can be adjustable: heavy rain, moderate rain, drizzling rain or haze.) 4. Provide the best high-power sprinkle pumps quality of the national,And with fire coupling, self-flow add self- priming function. |
Sprinkling area(m) |
»14m |
| Vertical suction | »7m |
Watering pressure |
250-450Mpa |
| Pump style | Self-priming centrifugal pump |
Manhole |
Man way access hole on top of tank;1 units DN500mm manhole |
Man walk way |
With skid resistance man walk way on top of tank |
Horse reels |
Two 75 ft hose reels at each side of the truck |
Water pump |
Water pump model: CLW80QZF-60/90N (N/S) Water pump flow rate(L/m): 60m3/h Head of delivery(m): 90m Self-priming function(min/4m):1.56 Efficiency(%):95% |
Electric system |
VDO electric system ,24V,negative grouped |
| Tool | Standard equipment |
