Desenho da barraca

Aluminum frame: packed in membrane film
Steel component: packed in wooden pallet
Roof and sidewall fabric: packed in PVC carry bag

Specifications

Desenho da barraca :
1.Aluminium Alloy frames
2.Double pvc-coated,fire/water proof,UV resistant PE cover

      Desenho da barraca

            A shape , No pole inside



We are one of the leading manufacturers in Guangzhou China having specialized in clear span tent

 for 11 years.Our Clear span tents are the perfect solution for any event,wedding, party, warehouse ect.

 The sleek structure is made of an aluminum frame covered with a PVC fabric. Since frame tents do not

 rely on tension, a minimal number of stakes is required and there is no need for center poles to support

the tent. Thus, our tent  can be in maximum utilization.

 Picture show



Specification
G series tent
Item	Width (m)	Eave height (m)	Bay Distance(m)	Ridge Height (m)	Roof pitch	Max. wind load
G6	6	2.9	3/5	4.10	200	80km/h
G9	9	2.9	3/5	4.60	200
G12	12	2.9	3/5	5.20	200
G15	15	2.9	3/5	5.70	200
The length can be unlimitedly extended by 3m section , such as  9m,12m,18m,21m…  Cutomer-made is ok.



 Frame,Material Data

1.Frame material:  Hard pressed aluminum alloy (over 15~20years life span)

2. Cover fabric material: 650~850g/sqm double PVC-coated polyester textile

  100% waterproof, flame retardant to DIN4102 B1 UV resistant, tear resistant

3. Flame retardant: DIN4102  B1/M2

4. Steel components: Hot-dip galvanized steel, thickness is over 60um;



 Charactor &Feature

> 100% relocatable, and unobstructed free span space;

> very easy and very fast to install and dismantle,convenient to stock and transport

> rainproof, fire retardant, UV-protection, can be environmentally controlled in any climate;

> Wind load: max. 100km/h,Snow load: 75kg/sqm

>Favorable temperature condition: -30 degree Celsius~+70 degree Celsius

>Sizes can be customized

> No pole inside, 100% interior space is available

>Made by advanced CNC technology

>All of our factory operations are strictly conducted in accordance with ISO 9001:2000 quality control standard. Product quality is under CE/GS (TUV) quality management system.



 Other Series of tent (Click picture for more details)

25m width Tent	20m clear span pvc Tent
5m pvc Tent	30m Clear span Tent

Optional accessaries



• Fabric: Colorful fabric, transparent fabric;

• Flooring system: economic plain wooden flooring, VIP cassette flooring;

• Door: rolling door,glass door(single door, double- wing glass door, sliding door, automatic glass door, fire glass door )

• Wall:  hard PVC wall , glass wall, ABS wall, sandwiched wall;

• Decoration :  roof linings ,  curtains , lighting;

• Furniture: sofa, tables, chairs, carpet, A/C, fence, conditioner, Heating etc;


• Equipment: anchor, weight plate, weight plate cover,  ramp, ventilation system,
  rain gutter system, digital printing, etc.






Please feel free to contact with us if you have any demands or questions on our products or services. We are devoted to providing support solutions to you with reasonable price and professional service.
