Led Tube t8 Indoor Lightings 2835 Smd 105pcs Led Chip With Microwave Motion Sensor

Led Tube t8 Indoor Lightings 2835 Smd 105pcs Led Chip With Microwave Motion Sensor photo-1
US$ 1 - 10 MOQ: 25 Pieces
Key Specifications
Get Latest Price
LED Light Source:
smd2835
Warranty(Years):
3
Input Voltage(V):
AC100-265V
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
LED Light Source smd2835
Warranty(Years) 3
Input Voltage(V) AC100-265V
Lamp Power(W) 18
Lamp Luminous Flux(lm) 1750
Lamp Luminous Efficiency(lm/w) 100
Color Temperature(CCT) Other, 3000-7500K
Working Temperature(℃) -20, 60
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum Alloy
IP Rating IP44
Certification CCC, CE, CQC, C-tick, Energy Star, EMC, ETL, FDA, FCC, LVD, PSE, REACH, SAA, UL, VDE
Place of Origin Guangdong, China
Brand Name Socreat
Model Number T8

Specifications

microwave motion sensor
1.High sensitivity and wide sensor area
2.Delay time adjustable
3.Radar controlled
4.CE,RoHS,FCC

  led microwave motion sensor

1. microwave motion sensor principle:

1, Radar controlled, test ambient movement intelligently, auto-adjust work state.

2, When driving a car closer and closer(5-10meters, adjustable), auto-sensor receive signal and transmit to let light fully work at 18W, equals to 45W fluorescent .

3, After your car parked and left, auto-sensor will automatically turn down at 5W(adjustable) for energy saving.



led tube t8 indoor lightings 2835 smd 105pcs led chip with microwave motion sensor



            A.Without any movement  30% brightness 5W(adjustable)                                B. People or car movement 100% brightness 18W



2. microwave motion sensor specs & series:



Type:SC-T8-06-600mmSC-T8-06-1200mmSC-T8-06-1200mm  SC-T8-06-1500mm    SC-T8-06-1800mm
Watt:

Movement: 9w

Slience: 3.5w

Movement: 18w

Slience: 5w

  Movement: 20w

 Slience: 6w

  Movement: 25w

 Slience: 7.5w

  Movement: 25w

 Slience: 7.5w

LED qty: 60pcs of 2835SMD  105pcs of 2835SMD 105pcs of 2835SMD 150pcs of 2835SMD150pcs of 2835SMD
Max Lumens:  >850lm  >1750lm  >1900lm  >2580lm>2580lm
  Size:   Φ26*L600mm  Φ26*L1200mm  Φ26*L1500mm  Φ26*L1500mmΦ26*L1800mm
Sensor area:  5-10m(adjustable)
Sensor angle:   140 degree
Lighting last:   30s(adjustable)
React time:   0.5s
Working voltage:   AC100-265V
Lighting angle:   120 degree
CRI:   >75Ra
Color temperature:   3000-7500K(Warm White/Neutral White/Pure White)
Power factor   >0.92
Lifespan:   ≥30000H
Material:   AL (good quality for heat dissipation) +PC
Working temperature:   -20~+60°C

 led tube t8 indoor lightings 2835 smd 105pcs led chip with microwave motion sensor

led tube t8 indoor lightings 2835 smd 105pcs led chip with microwave motion sensor

3. microwave motion sensor advantages:



1. Saving up 90% more than fluorescent tube, 60% more than normal LED T8.

2. Internal and isolation power supply, more safe.

3. Low decay below 3% in 10,000 hours service.

4. All LEDs light up immediately, even switch on/off often, it will not affect lifetime.

5. Special circuit design, any individual LED failure will not cause other LEDs in working condition to black out.

6. Compare to PIR sensor T8 and voice controlled T8, avoid air machine, automobile horn, ambient temperature interruption.



4. microwave motion sensor applications:



Parking lot, basement, elevator, passageway, washroom, park, bus station, villa and other 24hours lighting area.



led tube t8 indoor lightings 2835 smd 105pcs led chip with microwave motion sensor led tube t8 indoor lightings 2835 smd 105pcs led chip with microwave motion sensor

led tube t8 indoor lightings 2835 smd 105pcs led chip with microwave motion sensor led tube t8 indoor lightings 2835 smd 105pcs led chip with microwave motion sensor



5. microwave motion sensor certificate:



led tube t8 indoor lightings 2835 smd 105pcs led chip with microwave motion sensorled tube t8 indoor lightings 2835 smd 105pcs led chip with microwave motion sensor

led tube t8 indoor lightings 2835 smd 105pcs led chip with microwave motion sensorled tube t8 indoor lightings 2835 smd 105pcs led chip with microwave motion sensor



6. microwave motion sensor Quality guarantee:

led tube t8 indoor lightings 2835 smd 105pcs led chip with microwave motion sensor



7. microwave motion sensor Installation:

led tube t8 indoor lightings 2835 smd 105pcs led chip with microwave motion sensor

1, Remove fluorescent tube, also remove starter & ballast.

2, Install microwave motion sensor.



8. microwave motion sensor Remarks:



This is Parker from Socreat, welcome to contact us!

Designer Custom microwave motion sensor.
