Led Tube t8 Indoor Lightings 2835 Smd 105pcs Led Chip With Microwave Motion Sensor
Specifications
microwave motion sensor1.High sensitivity and wide sensor area
2.Delay time adjustable
3.Radar controlled
4.CE,RoHS,FCC
led microwave motion sensor
1. microwave motion sensor principle:
1, Radar controlled, test ambient movement intelligently, auto-adjust work state.
2, When driving a car closer and closer(5-10meters, adjustable), auto-sensor receive signal and transmit to let light fully work at 18W, equals to 45W fluorescent .
3, After your car parked and left, auto-sensor will automatically turn down at 5W(adjustable) for energy saving.
A.Without any movement 30% brightness 5W(adjustable) B. People or car movement 100% brightness 18W
2. microwave motion sensor specs & series:
| Type: | SC-T8-06-600mm | SC-T8-06-1200mm | SC-T8-06-1200mm | SC-T8-06-1500mm | SC-T8-06-1800mm |
| Watt: | Movement: 9w Slience: 3.5w | Movement: 18w Slience: 5w | Movement: 20w Slience: 6w | Movement: 25w Slience: 7.5w | Movement: 25w Slience: 7.5w |
| LED qty: | 60pcs of 2835SMD | 105pcs of 2835SMD | 105pcs of 2835SMD | 150pcs of 2835SMD | 150pcs of 2835SMD |
| Max Lumens: | >850lm | >1750lm | >1900lm | >2580lm | >2580lm |
| Size: | Φ26*L600mm | Φ26*L1200mm | Φ26*L1500mm | Φ26*L1500mm | Φ26*L1800mm |
| Sensor area: | 5-10m(adjustable) | ||||
| Sensor angle: | 140 degree | ||||
| Lighting last: | 30s(adjustable) | ||||
| React time: | 0.5s | ||||
| Working voltage: | AC100-265V | ||||
| Lighting angle: | 120 degree | ||||
| CRI: | >75Ra | ||||
| Color temperature: | 3000-7500K(Warm White/Neutral White/Pure White) | ||||
| Power factor | >0.92 | ||||
| Lifespan: | ≥30000H | ||||
| Material: | AL (good quality for heat dissipation) +PC | ||||
| Working temperature: | -20~+60°C | ||||


3. microwave motion sensor advantages:
1. Saving up 90% more than fluorescent tube, 60% more than normal LED T8.
2. Internal and isolation power supply, more safe.
3. Low decay below 3% in 10,000 hours service.
4. All LEDs light up immediately, even switch on/off often, it will not affect lifetime.
5. Special circuit design, any individual LED failure will not cause other LEDs in working condition to black out.
6. Compare to PIR sensor T8 and voice controlled T8, avoid air machine, automobile horn, ambient temperature interruption.
4. microwave motion sensor applications:
Parking lot, basement, elevator, passageway, washroom, park, bus station, villa and other 24hours lighting area.


5. microwave motion sensor certificate:
6. microwave motion sensor Quality guarantee:
7. microwave motion sensor Installation:
1, Remove fluorescent tube, also remove starter & ballast.
2, Install microwave motion sensor.
8. microwave motion sensor Remarks:
This is Parker from Socreat, welcome to contact us!
Designer Custom microwave motion sensor.
