XCMG Mini Wheel Loader LW188 With YTO Engine LR4105G72DA, Type of the Mine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
XCMG
Model Number:
LW188
Payment & Shipping
Payment Methods:
Port of Shipment:
lianyungang port and other chinese port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Brand Name
XCMG
Model Number
LW188
Place of Origin
Jiangsu, China
Type
Front Loader
Moving Type
Wheel Loader
Dimension(Long * Breadth * High)
5685x1960x2315 mm
Rated Load
1.8t
LW188 wheel loader is with reasonable design, the machine adopts hydraulic mechanical drive, and four-wheel drive, featuring larger drive force and digging force; with small turning radius and convenient and agile operation, it is suitable for narrow working area.
Z type bucket linkage, single arm, lifting cylinder of high pivot, strong digging force and short working cycle time, and higher working efficiency.
Priority of on-demand oil supply for all hydraulic load-sensing steering and priority of single pump valve working hydraulic system, economic in energy-saving.
With openable rear hood side door and full visibility, the cab provides the comfortable working environment and advantaged maintenance condition
Z type bucket linkage, single arm, lifting cylinder of high pivot, strong digging force and short working cycle time, and higher working efficiency.
Priority of on-demand oil supply for all hydraulic load-sensing steering and priority of single pump valve working hydraulic system, economic in energy-saving.
With openable rear hood side door and full visibility, the cab provides the comfortable working environment and advantaged maintenance condition
Item |
unit |
value |
Rated load |
t |
1.8 |
Rated load |
t |
2350/2700/3000 |
Dumping distance |
mm |
850 |
Lifting time |
s |
≤5 |
Total time of three devices |
s |
≤10 |
Digging force |
kN |
50 |
Articulated angle |
35±1 |
|
Wheeelbase |
mm |
2200 |
Tread |
mm |
1490 |
Speed | ||
Ⅰgear(F/R) |
km/h |
6/6 |
Ⅱgear(F/R) |
km/h |
24/24 |
Diesel engine | ||
Diesel engine |
LUOTUO (YTO) |
|
Model |
LR4105G72DA |
|
Type |
Natural intake |
|
Rated |
kW |
60 |
Rated speed |
r/min |
2400 |
Dimension(LxWxH) |
mm |
5520X1960X2850 |
Overall weight |
t |
6.0 |
Tyre specification |
16/70-20 |
|
MINE TYPE
MINE TYPE
