Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Loader > Skid Steer Loader JC45
Skid Steer Loader JC45
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
Juling
Model Number:
JC45
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Brand Name
Juling
Model Number
JC45
Place of Origin
Shandong, China
Type
Skid Steer Loader
Moving Type
Wheel Loader
Dimension(Long * Breadth * High)
3200x1740x2030mm
Rated Load
1400kg
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Skid Steer Loader JC451. Operation weight: 700kg
2. Rated Power: 50hp
Skid Steer Loader JC45
Parameter
| Specifications | |
| Rated operatingcapacity(kg) | 700 |
| Tipping load(kg) | 1400 |
| Bucket capacity(m3) | 0.36-0.45 |
| Operationg weight(kg) | 2600 |
| Max. travel speed(km/h) | 12 |
| Hydraulic pump flow(L/min) | 62.5 |
| Fuel tank capacity(L) | 50 |
| Tires | 10.0/75-15.3 |
| Overall dimensions(mm) | 3200×1740×2030 |
| Dimensions | |
| Height at maximum extension(mm) | 3670 |
| Height to bucket hinge pin(mm) | 2900 |
| Width with bucket(mm) | 1740 |
| Track width(mm) | 1450 |
| Wheelbase(mm) | 991 |
| Ground clearance(mm) | 185 |
| Dump angle | 40° |
| Dumping height(mm) | 2310 |
| Maximum reach(mm) | 710 |
| Engine | |
| Maker/Model | XINCHAI 490BPG |
| Net power | 50hp/2650rpm |
| Type | 4 Cylinder in-line, Water cooled,4 stroke,Dieselengine |
| Displacement(L) | 2.54 |
| Standard | |
| Open-type operator cab | |
| Hand control system(Mechanical type) | |
| Standard bucket | |
| Auxiliary hydraulic couplers | |
| Optional | |
| Enclosed operator cab with A/C | |
| Cabfitted with a heater as standard | |
| Hydraulic joystick controls | |
| Backhoe,Breaker,Angle blade,Auger,Sweeper,Pallet fork,Combinition bucket,Mower,Asphalt cutter,and More | |
