KaiFan Light-duty P Series (FOTON) Road Wrecker KFM5071TQZ13P

Items

Unit

Value

Boom Structure

Rated towing weight

kg

7400

Max. Lifting weight

kg

1500

Max. Lifting weight of full extending boom

kg

800

Effective length of boom

mm

1928

Extension traveling of boom

mm

1200

Elevation of boom (upper/ lower)

°

7~-10

Platform Structure

Min. Elevation of full extending platform

°

11

Max. Loading of platform

kg

3000

External dimension of platform (length×width×height)

mm

5200×2120×57

Ground clearance of cage floor

mm

1041

Max. Pulling power of winch

kg

4000

Dia. Of steel cable

mm

10

Length of steel cable

m

25

Min. Speed of steel cable

m/min

2.5

Vehicle

Parameters

External dimension

mm

7555×2200×2560

Chassis model

BJ1071VCJFA-S

Drive

4×2

Axle base

mm

3800

The whole weight of empty load

kg

4595

Load of front axle of empty load

kg

1815

Load of rear axle of empty load

kg

2780

The whole weight of full load

kg

7495

Load of front axle of full load

kg

2850

Load of rear axle of full load

kg

4645

Wheel base (front/rear axle)

mm

1685/1600

Front suspension

mm

1120

Rear suspension

mm

2220

Approach angle

º

22

Departure angle

º

8

Max. Speed

km/h

95

Max. Grade ability

%

≥28

Min. Turning diameter

m

≤16

Min. Ground clearance

mm

190

Engine model

-

CA4DC2-12E3

Rated power

kw/r/min

88/3200

Engine emission

ml

3168

Max. Torque

n·m/r/min

320/1900-2100

Fuel type

Diesel

Standard of emission

EN III

Tire size

7.50-16,8.25-16

Persons

3
