Industrial Fan Heater 15kw
- 10000 Piece / Pieces per Month
- NINGBO CHINA
- T/T
- Heater Core Heater Welding Gun Heater Element
- Industrial Diesel Heater /Agricultural Vegetable Planting/Aquaculture Industry Heater
- Preheating equipment for hardbandig welding
- Heater Core Heater Welding Gun Heater Element
- DL-3 model electric air heater with upper outlet and lower inlet
- DL-2 model electric air heater with Left-Right Circulation
Product Details
Condition: | New | Type: | Air Heater | Power Source: | Electric |
Place of Origin: | Zhejiang, China | Brand Name: | AOLIPU or OEM | Model Number: | ALP-RE015 |
Dimension(L*W*H): | 408*342*547mm | Weight: | 15.9kgs | Voltage: | 380-400V/50Hz |
Power(W): | 15000W | Certification: | CE | Warranty: | One year |
After-sales Service Provided: | Overseas third-party support available |
Product Description
Industrial Fan Heater 15kw
1.5kW-22kW, 17000BTU-75100BTU
2.Full metal body, powder coated
3.Stainless steel heating element
4.Adjustable thermostat control
5.CE,GS,ROHS,IP44
Features:
Electric Indusrial Fan Heater series:
Model No.: RE005A, RE009A, RE009, RE012, RE015, RE018, LXF022.
230V-380V~50Hz, 5kW-22kW,
1. Stainless steel heating element
2. Adjustable thermostat control
3. Over heat protection
4. With fan, cool blow available
5. Whole metal casing by powder against rustiness
6. With insulated handle, easy to carry
7. Protection Class IP44
8. CE/GS/ROHS
Electric Industrial Fan Heater parameters:
Model No. | RE005A | RE009A | RE009 | RE012 | RE015 | RE018 | LXF22 |
Power Setting (W) | 30/1650/5000 | 52/3000/9000 | 52/3000/9000 | 90/4000/12000 | 90/5000/15000 | 90/6000/18000 | 110/11kW/22kW |
Rating Power (kW) | 5 | 9 | 9 | 12 | 15 | 18 | 22 |
(Kcal/h) | 4300 | 7750 | 7750 | 10300 | 12900 | 15500 | 18900 |
(Btu/h) | 17000 | 30700 | 30700 | 40900 | 51200 | 61450 | 75100 |
Power Supply (V/Hz) | AC400V/50Hz | AC400V/50Hz | AC400V/50Hz | AC400V/50Hz | AC400V/50Hz | AC400V/50Hz | AC400V/50Hz |
Phase | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
Air Output (M3/h) | 550 | 800 | 800 | 1700 | 1700 | 1700 | 2200 |
Plug | Euro plug | Euro plug | Euro plug | Euro plug | Euro plug | Euro plug | Euro plug |
Cable | With | Without | Without | Without | Without | Without | Without |
G.W./N.W. (KG) | 8/7 | 9.5/8.5 | 11.9/10.9 | 16/15 | 16.5/15.5 | 16.5/15.5 | 19.2/18.0 |
Product (MM) | 240*280*430 | 331*309*428 | 331*339*438 | 408*342*547 | 408*342*547 | 408*342*547 | 430*430*610 |
Packing (MM) | 320*290*460 | 350*350*460 | 380*350*480 | 460*395*570 | 460*395*570 | 460*395*570 | 485*485*640 |
PC/CTN | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
Loading Qty. (PC) | 630/ 1200/ 1400 | 504/ 1008/ 1176 | 500/ 1000/ 1150 | 300/ 600/ 705 | 300/ 600/ 705 | 300/ 600/ 705 | 144/ 288/ 384 |
20'GP/ 40'GP/ 40'HQ | |||||||
Approval | CE, ROHS | CE, GS, ROHS | CE, GS, ROHS | CE, ROHS | CE, ROHS | CE, ROHS | CE, ROHS |
Company Introduction:
* Company history: established in 2001. professional manufacturer of Industrial Heaters.
* Products items:Industrial electrical fan heater, Diesel/kerosene heater, LPG gas heater
* Main markets: Russia, Ukraine, Germany, Denmark, Sweden, Finland, UK, France, Australia, Egypt.
* Employees: 100-300
* Production capacity: 6 assemblying lines , 500,000 pcs/ year,
* Quality management system: ISO9001:2008
Application sites:
Mobile Industrial Heaters and Industrial Fan Heaters are suitable
for workshop, Greenhouse,
construction site, factory workshops, warehouses, tents, gym,
yoga hall, training hall, game hall, etc.
Easy to operate, easy to install, safe to use, small size, easy to
move, long life, protection devices
equipped with flame and over heat protection.
