3TF46 45Amp AC Contactor From China

FOB Price

US$ 1 - 20 / Piece

100 Pieces(Min. Order)

Port Ningbo
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	GWIEC
Model Number	CJX1/3TF-46 45A	Electricity Type	AC
Number of Pole	3	Phase	3
Main Circuit Rating Voltage	Other, 110~660V	Main Circuit Rating Current	Other, 0~630A

Product Description

Specifications

1.Current:up to 630A
2.Voltage:up to 660v
3.Can install contact blocks
4.Long life-span
5.3TF Motor Protective Contactor

3TF series AC contactor are suitable in electrical system with AC 50/60Hz, rated operational voltage up to 660V. In AC-3 usage, rated operational voltage up to 380V, rated operational current up to 630A to make or break remote motors or system. They form electromagnetic starters with suitable thermal overload or phase-failure. They are made according to IEC 60947, BS 5424 & VDE 0660.

The contactor is a straight motion mechanism having double breaking contacts. The auxiliary contacts are arranged NO.2NC at most, it is employed the flexible locking connection between the contact support and core, three are no arcisolated panel in the Ie≤22A contactor. In the In≥32A contactors. Three are moulded arc-chute with arc-isolated panel, because all contacts are made of high cnonfusibility and against corrosion silver alloy. All series products can be mounted by screw, Ie≤32A contactor also by installation rail.

CJX1/3TF-46 45A AC Contactor from China

Stye					GK 3TF44	GK 3TF45	GK 3TF46	GK 3TF47	GK 3TF48	GK 3TF49	GK 3TF50	GK 3TF51	GK 3TF52	GK 3TF53	GK 3TF54	GK 3TF55	GK 3TF56
Rated Insulation Voltage, Ue					680V	690V	1,000V
Rated Current, Ie (380V) A				AC-3	32	38	42	63	75	85	110	140	170	205	250	300	400
Rated Current, Ie (380V) A				AC-4	15.6	18.5	24	28	34	42	54	68	75	96	110	125	150
Motor Power, 50Hz, kW	AC-3		230/220V		8.5	11	15	18.5	22	26	37	43	55	64	78	93	125
			400/380V		15	18.5	22	30	37	45	55	75	90	110	132	160	200
			500V		21	25	30	41	50	59	76	98	118	145	178	210	284
			690/660V		23	23	39	55	67	67	100	100	156	156	235	235	375
			1000V		-		-	-	39	39	65	65	90	90	132	132	150
	AC-4	400/380V			7.5	9	12	14	17	21	27	35	38	50	58	66	81
	AC-4	690/660V			13	15.5	20	24	29	36	46	60	66	86	100	144	140
Mechanical Life					10x10⁶
Electrical Life				AC-3	1.2x10⁶
Electrical Life				AC-4	0.2x10⁶
Conventional Heating Current (A)					55	55		90	100	100	160	160	210	220	300	300	400
Pick-up Voltage of Coil					(0.8-1.1)Ui
Weight (kg)					0.68	0.68	1.4	1.4	2.3	2.3	3.3	3.3	4.8	4.8	6.2	6.2	8.5
