NEMA23 Hybrid Stepper Motor Frame Size 57mm
USD $5 - $12
/ Piece
50 Pieces(Min.Order)
- 50000 Piece / Pieces per Month
- Ningbo/Shanghai
- T/T Credit Card
You May Like
- High speed Micro 385 Brush DC Motor for Electric Appliance Tools 3.7V 24V
- DC motor from Haiyan Long Bo factory for Hydraulic equipments
- traction motor GE761,D77/78,GE752,D29
- Maxon motor
- High torque BLDC tattoo motor 2016RB low-start voltage diameter 20mm tattoo motor long lifespan tattoo motor for tattoo gun
- High torque BLDC tattoo motor 2016RB low-start voltage diameter 20mm tattoo motor long lifespan tattoo motor for tattoo gun
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | GWIEC | Model Number: | J-5718HB5401 |
Usage: | Home Appliance, Other | Type: | Other, Gear Motor, Hybrid Step Motor | Torque: | 3.1 N.m |
Commutation: | Brushless | Continuous Current(A): | 4.4 |
Product Description
Features:
1. High Torque
2. Low Noise
3. Customized Motor
4. Long life span
Specifications:
Step Angle | 1.8° (±5%@ full step, no load) |
Resistance Accuracy | ±10% |
Inductance Accuracy | ±20% |
Temperature Rise | ≤80K |
Ambient Temperature | -20°C to 50°C |
Shaft Radial Play | ≤0.02mm @ 450g-load |
Shaft Axial Play | ≤0.02mm @ 450g-load |
Max Radial Force | 75N @ 20mm from flange |
Max Axial Force | 15N |
Dielectric Strength | 500VAC for one minute |
Insulation Resistance | ≥100MΩ, 500VDC |
Product Description
Model | Holding Torque | Rated Current | Resistance | Inductance | Lead Wire | Rotor Inertia | Weight | Height | ||
N·m | oz-in | A/Phase | Ω/Phase | mH/Phase | PINS | g.cm2 | oz-in2 | kg(lb) | mm(inch) | |
J-5718HB1401 | 0.64 | 91 | 2.4 | 1.2 | 2.4 | 4 | 120 | 0.66 | 0.44(0.97) | 40.5(1.32) |
J-5718HB1402 | 1.7 | 2.2 | 4.9 | |||||||
J-5718HB1403 | 1.2 | 4.4 | 9.7 | |||||||
J-5718HB1404 | 0.85 | 8.7 | 19.2 | |||||||
J-5718HB2401 | 1.3 | 184 | 3.5 | 0.8 | 2.4 | 260 | 1.42 | 0.67(0.62) | 53.5(1.56) | |
J-5718HB2402 | 2.5 | 1.5 | 4.7 | |||||||
J-5718HB2403 | 1.75 | 3 | 10.3 | |||||||
J-5718HB2404 | 1.25 | 5.7 | 18.6 | |||||||
J-5718HB3401 | 2.3 | 326 | 4.4 | 0.76 | 2.5 | 450 | 2.46 | 1.04(0.77) | 75.5(1.87) | |
J-5718HB3402 | 3.1 | 1.4 | 5 | |||||||
J-5718HB3403 | 2.2 | 2.8 | 10 | |||||||
J-5718HB3404 | 1.6 | 5.4 | 19.6 | |||||||
J-5718HB4401 | 2.5 | 354 | 4.4 | 0.81 | 3 | 520 | 2.84 | 1.14(1.04) | 59.5(2.34) | |
J-5718HB4402 | 2.2 | 3.1 | 11.8 | |||||||
J-5718HB1401 | 3.1 | 439 | 4.4 | 0.95 | 5 | 680 | 3.72 | 1.46(3.22) | 99.5(2.34) |
Wiring: Connector / PIN
Exterior Diagram
Shaft Type
