Help CenterRubber Air Hose
Related Products
Feature:
Air Rubber Hose
Tube:SBR blended,black,smooth
Reinforcement:textile braided high tensile
synthetic yarn
Cover:EPDM/SBRblended.black,smooth/corrugated,
weather and ozone ,abrasion resistant
Product name:air rubber hose/rubber air hose
1.Material:SBR Natural rubber
2.Size: 1/4", 5/16", 3/8",1/2",5/8",3/4",1"
3.Color: Red, blue, black, green, yellow, same price for different colors
4.Logo: company logo can be imprinted on the rubber hose
5.Working pressure: 300PSI(20Bar)
6.Bursting pressure: 900PSI(60Bar)
7.Structure: Inside bond layer + reinforcing layer ( second reinforcing layer for1/2",5/8",3/4",1")
8.outside bond layer; outside surface is mill finish, reinforcing layer is braid fiber with high
9.retractility,weather and ozone,abrasion resistant
10.Application: wide rang service in general industrial service,pneumatic tools,and mobils shop
11.Temperature:-40`C~+90`C
high pressure air rubber hose/air hose
| size | I.D | O.D | line layer | W.P | B.P | Standard length | net weight | measure-ment |
| inch | mm | mm | bar | bar | m/roll | kg/roll | m3/roll | |
| 1/4 | 6 | 13 |
1 | 20 | 60 | 100 | 18 | 0.032 |
| 5/16 | 8 | 15 | 1 | 20 | 60 | 100 | 22 | 0.035 |
| 3/8 | 10 | 17 | 1 | 20 | 60 | 100 | 24 | 0.043 |
| 1/2 | 12.5 | 21 | 2 | 20 | 60 | 100 | 43 | 0.085 |
| 5/8 | 16 | 25 | 2 | 20 | 60 | 100 | 48 | 0.150 |
| 3/4 | 19 | 28 | 2 | 20 | 60 | 100 | 58 | 0.170 |
| 1 | 25 | 35 | 2 | 20 | 60 | 100 | 42 | 0.1 |
packing:can use pvc film, paper card,nylon bag,shrink wrapped ,carton box, or as your requirement
in the quality condition,we have strict quality control, to ensure the best quality
Please feel free to contact us for more details
Trademanager:cn204109000
Tel:0575-87061613
Fax:0575-87618766
