2014 China Time Go Best-selling 3 Axles Flatbed Semi Trailer

Name: 2014 China Time Go Best-selling 3 Axles Flatbed Semi Trailer
Brand: Time Go
SKU: 112254277
Availability: InStock

US$ 11,600 - 18,000 MOQ: 1 Unit

Key Specifications

OEM No.:

3708322800116

Max Payload:

50t

Size:

12500*2500*1560mm

Weihai King-Life Sports Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

OEM No. 3708322800116

Max Payload 50t

Size 12500*2500*1560mm

Place of Origin Shandong, China

Brand Name Time Go

Model Number semi trailer

Specifications

Use: Truck Trailer Type: Semi-Trailer Material: Steel Certification: ISO9001,CCC,BV,SGS
Size: 12500*2500*1560mm

flatbed semi trailer
1.FUWA or BPW axle
2.Loading 20ft or 40ft container
3.With ISO9001,CCC,BV,SGS,CO,CIQ,FORME,FORMF,TUV

Trucks Trailer:

Tare Weight	About 7.5T
Dimension	12500mm2490mm1575mm
Loading Capacity (T)	≤ 45 T
Axle	3 axles, 13 T FUWA /Huajing Brand
Rim	9.00-22.5
Tire	12.00R22.5 Triangle Brand 12pieces
Suspension	Mechanical suspension (America Type)
Spring leaf	90(W)mm13(Thickness)mm10 Layer
King pin	JOST brand 3.5inch bolts type
Support leg	China brand 28Tons (Double speed)
Main beam	Height: 500mm, upper plate is 14mm, middle plate is 8mm, Down plate is 16mm; Material is Q345B Steel.
Side beam	16mm channel steel (Material is Q235steel).
Platform	3mm diamond platform
Side wall	Height is 800mm, you can choose freely.
Brake chamber	WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); One piece of 45L air tanks
ABS	Without
Twist Locks	Eight pieces (Lifting type)
Valve	WABCO valve
Light	LED light
Voltage	24V
Receptacle	7 ways (7 wire harness)
Tool box	One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar)
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Shipping Terms:	By bulk cargo carrier, RORO or 40HQ container.
