China TIME GO 3 Axles Container Truck Trailer Semi Trailer

Name: China TIME GO 3 Axles Container Truck Trailer Semi Trailer
Brand: TIME GO
SKU: 112254111

US$ 30,000 - 100,000 MOQ: 1 Unit

Key Specifications

OEM No.:

370832200009857

Max Payload:

50t

Size:

14030*2500*1850

Weihai King-Life Sports Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

OEM No. 370832200009857

Max Payload 50t

Size 14030*2500*1850

Place of Origin Shandong, China

Brand Name TIME GO

Model Number semitrailer

Specifications

Use: Truck Trailer Type: Semi-Trailer Material: Steel Certification: CE Size: 14030*2500*1850 Max Payload: 50T

1.ISO9001 CCC
2.strong steel
3.different weight and capacity
4.excelent performance
5.low price ,high quality

50t 3axles LOW BED SEMI TRAILER

Fuction:Delivery for Excavator, Machinery, Road Roller, Containers, Groceries

We are manufacturer.

Tare Weight	About 8.5-13T
Dimension	12000mm-18000mm2500mm-3500mm3050mm Please indicate the working platform height and length.
Loading Capacity (T)	30T-100T
Axle	13 T/16T, FUWA /BPW Brand
Rim	6.5-20/7.5-20/8.00-20/8.5-20
Tire	8.25R20/10.00R20/11.00R20/12.00R20
Suspension	Mechanical suspension (Germany Type or America Type) Or Air suspension (China brand or BPW brand )
Spring leaf	90(W)mm13(Thickness)mm10 Layer or 100mm12mm12
King pin	JOST brand 2.0 or 3.5inch bolts type or Welding type
Support leg	JOST brand D200T or China brand 28Tons (Double speed)
Main beam	Height: 450mm-520mm, upper plate is 14mm-25mm, middle plate is 8mm-12mm, down plate is 16mm-25mm ; Material is Q345B Steel .
Side beam	16mm -25mm channel steel ( Material is Q235steel ).
Ladder	Manual or Hydraulic type
Gooseneck	For choose
Brake chamber	WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); Two pieces of 45L air tanks
ABS	Optional
Twist Locks	Four ,Eight or Twelve pieces (Lifting type or Twist Screw Type)
Valve	WABCO valve
Light	LED light
Voltage	24V
Receptacle	7 ways (7 wire harness)
Tool box	One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar)
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Shipping Terms:	By bulk cargo carrier, RORO or 40HQ container.

DIMENSIONS container truck
Tare weight	6000KGS	Payload	45000KGS
Overall length	12450mm	Overall Width	2480mm
SPECIFICATION
Chassis	Heavy duty and extra durability designed I beam;opting for high tensile steel Q345,welded by automatic submerged-Aac processes.Top flange 14mm,width140mm;Middle Flange 6mm;bottom flange16mm,width 140mm
Axle	2 axles
	Brand name:BPW.L1 or FUWA –optional upon choice
Suspension	Mechanical suspension or air suspension
Spring	Leaf spring or air bag
King pin	JOST brand2’’ bolt-in king pin
Twist lock	12 no.of ISO twist lock for 1x20ft,2x20ft,1x40ft container
Landing gear	JOST brand two-speed,manual operating ,heavy duty landing gear
Wheel rim	8.5-20,9.0-20,8.25-22.5,9.0-22.5 steel wheel rim optional upon choice
Tyre	11.00R20,12.00R20,11R22.5,12R22.5,315/80R22.5 tire optional
Spare tire	One set of spare tire including a carrier
Braking system	WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks
Paiting	Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint
Accessories	One standard tool box
