China TIME GO Trailer 2 or 3 Axles 40ft Container Flat Bed Trailer

Name: China TIME GO Trailer 2 or 3 Axles 40ft Container Flat Bed Trailer
Brand: TIME GO
SKU: 112254071
Availability: InStock

US$ 10,000 - 18,000 MOQ: 1 Unit

Key Specifications

OEM No.:

3708322800116

Max Payload:

40t

Size:

any size can be choose

Weihai King-Life Sports Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

OEM No. 3708322800116

Max Payload 40t

Size any size can be choose

Place of Origin Shandong, China

Brand Name TIME GO

Model Number semitrailer

Specifications

Use: Other Trailers OEM No.: 370832 Max Payload: 40T Size: any size can be choose Place of Origin: Shandong, China (Mainland)

Container Flat Bed Trailer
1.DN50 towing hook
2.Loading for 20ft or 40ft container
3.With 4 or 8 or 12 piees twist locks

container flat bed trailer

Tare Weight	About 5.6-8T
Dimension	12450mm2490mm1575mm (Size can be
Loading Capacity (T)	≤ 45 T
Axle	13 T/16T, FUWA /BPW /Huajing Brand
Rim	9.00-22.5
Tire	12.00R22.5/ 315 80R22.5
Suspension	Mechanical suspension (Germany Type or America Type) Or Air suspension (China brand or BPW brand )
Spring leaf	90(W)mm13(Thickness)mm10 Layer or 100mm12mm12
King pin	JOST brand 2.0 or 3.5inch bolts type or Welding type (Optional) Or use turntable (diameter is 1.1m)
Draw Bar	44 or 46mm square tube (length is 1.4m )
Tractor Hook	DN50
Support leg	Without
Main beam	Height: 500mm, upper plate is 14mm, middle plate is 8mm, down plate is 16mm ; Material is Q345B Steel .
Side beam	16mm or 18mm channel steel ( Material is Q235steel ).
Brake chamber	WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); Two pieces of 45L air tanks
ABS	Optional
Twist Locks	Four ,Eight or Twelve pieces (Lifting type or Twist Screw Type)
Valve	WABCO valve
Light	LED light
Voltage	24V
Receptacle	7 ways (7 wire harness)
Tool box	One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar)
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Shipping Terms:	By bulk cargo carrier, RORO or 40HQ container.
