Home > Transportation > Trailer > Other Trailers > Time Go 2axles 13meter Curtain Semi Trailer

Time Go 2axles 13meter Curtain Semi Trailer

Name: Time Go 2axles 13meter Curtain Semi Trailer
Brand: Time Go
SKU: 112253689

US$ 28,500 - 35,500 MOQ: 1 Unit

Key Specifications

OEM No.:

3708322800116

Max Payload:

30t

Size:

13000*2500*1800mm

Weihai King-Life Sports Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

OEM No. 3708322800116

Max Payload 30t

Size 13000*2500*1800mm

Place of Origin Shandong, China

Brand Name Time Go

Model Number Semi-Trailer

Curtain Semi Trailer:
1.We are manufacture
2.With ISO9001,CCC certificate
3.Loading capactiy:30T-40T
4.Length:8m to 14meter

Curtain Semi Trailer

Tare Weight	About 8.3T
Dimension	13000mm2490mm3600mm (Outerside)
Loading Capacity (T)	≤ 40 T
Axle	13 T/, FUWA or Huajing Brand
Rim	9.00-22.5
Tire	12.00R22.5
Suspension	Mechanical suspension (Germany Type or America Type)
Spring leaf	90(W)mm13(Thickness)mm10 Layer
King pin	JOST brand 2.0inch bolts type
Support leg	JOST brand C200T
Main beam	Height: 500mm, upper plate is 14mm, middle plate is 8mm, down plate is 16mm ; Material is Q345B Steel .
Side beam	16mm or 18mm channel steel (Material is Q235steel).
Side Wall	Height: 2m, the material tope beam lead rail is aluminum alloy, the material of both side wall is cord fabric, the top cross beam moving with the cord fabric, there are four pieces vertical beam each side , there is one layer of aluminum alloy plate between two beam. The logo can be choose freely .
Brake chamber	WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); Two pieces of 45L air tanks
Front and Back wall	Flat steel
Twist locks	4 pieces
ABS	Optional
Valve	WABCO valve
Light	LED light
Voltage	24V
Receptacle	7 ways (7 wire harness)
Tool box	One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar)
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Shipping Terms:	By bulk cargo carrier, RORO or 40HQ container.(if want shipping by containers ,the length should less than 12500mm )
