Specifications
Use: Truck Trailer Type: Semi-Trailer Material: Steel Certification: CE Size: 10000*2500*3970 OEM No.: 3708322800116Main Dimensions | |
Dimension | 10500*2300*1800mm (work space ) |
Tare weight | About 18000KGS |
Total Volume(m3) | 45m3 |
Payload | 75tons |
Side wall thickness(mm) | 4mm Q235 steel |
Bottom plate thickness(mm) | 6mm /Q235 steel |
Lifting system | Full set of Hyva (FC214-5-07130) Hydraulic Lifting Cylinder |
Chassis | |
Main Beams | Height:500mm, upper plate is 16mm,middle is 8mm(double+reinforcing plate),down plate is 18mm,material is Q345B steel |
Axle | 3 axles, FUWA brand 16tons per axles |
Landing Gear | JOST (C200T)(Special for exporting type) |
King Pin | JOST 3.5 inch bolt-in king pin (Special for exporting type) |
Suspension | America type (Special for exporting type) |
Leaf Spring | 90(W)mm*13(Thickness)mm*10 Layer (Special for exporting type) |
Pneumatic Braking System | WABCO RE 6 relay valve; Spring brake chamber; one piece of 45L air tanks. |
Rim | 8.00-20 China Brand |
Tire | 11.00R20 Triangle Brand |
ABS | Without |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Accessories | One standard tool box |
Shipping Terms | By Bulk Cargo or roro, the tractor truck can be choose 6*4 model . |
